安装之前
所有的资料是按最新出版的产品资料编写而成。
科勒公司保留任何时候不经通知即可改变产品特
性、包装或产品可供类型的权利。
说明书包括重要的安装、保养及清洁方面的内容，
请把这些资料交给用户阅读。
注意事项:
1. 一定要先彻底冲洗供水管以清除管道中的杂质,
使用水源为自来水或可供饮用水。
2. 请勿将强力及冲击施于产品，以免造成故障，
引起漏水。
3. 安装、清洁龙头时，切勿损伤感应窗口表面，
以免造成故障。
4. 如果是安装新的洗面盆，可将水龙头和排水组
件先安装到面盆上。
5. 安装时务必按照说明书的要求正确连接导线，
龙头安装完毕后才可向电源盒供电。
6. 对于冷热混水龙头，先将连接热水的角阀关
闭，以免烫伤。
7. 修理面盆时，用黑色电工胶布粘住感应窗口。
8. 维修交流龙头时，必须断开交流电源并关闭
水源。
1380339-T01-A
AVID DUO SENSOR FAUCET-COLD,AC,W/ P,0.5G
艾非皂液感应龙头-单冷,交流含电源盒,1.9升
AVID DUO SENSOR FAUCET-MIXER,AC,W/ P,0.5
艾非皂液感应龙头-冷热,交流含电源盒,1.9升
AVID DUO SOR FCT-MIXER,AC,W/ P,0.5G,IOT
艾非皂液感应龙头-冷热,交流含电源盒,1.9升,云智能版
科勒（中国）投资有限公司
中国上海市静安区江场三路158号 邮编：200436
制造商：上海科勒电子科技有限公司
中国上海市宝山区丰翔路1955号 邮编：200444
Avid Duo Sensor Faucet
BEFORE YOU BEGIN
All information is based on the latest product information
available at the time of publication, Kohler Co. reserves the
right to make changes to product characteristics, packaging,
or availability at any time without notice. Please deliver these
instructions for the consumer. They contain important
installation, maintenance and cleaning information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
Faucet is designed for tap water or potable water.
2. Handle the faucet with care to avoid damaged.
3. Do not damage the surface of sensing window when
installing or cleaning the faucet.
4. For new installations, install the faucet and drain to the
lavatory before installing the lavatory.
5. carefully follow the installation instructions provided.
Only provide to the electric power box after the installation
is conpleted.
6. For faucet with temperature mixer, please turn off valve
before connecting to hot water to avoid scalding.
7. Cover the sensing window with black tape when repairing
lavatories.
8. Turn off the electrical source and shut down water
supply before servicing faucet.
AVID
1
Advertisement
Table of Contents
Related Manuals for Kohler AVID DUO 29936T-CP
Summary of Contents for Kohler AVID DUO 29936T-CP
- Page 1 安装之前 BEFORE YOU BEGIN All information is based on the latest product information 所有的资料是按最新出版的产品资料编写而成。 available at the time of publication, Kohler Co. reserves the 科勒公司保留任何时候不经通知即可改变产品特 right to make changes to product characteristics, packaging, 性、包装或产品可供类型的权利。 or availability at any time without notice. Please deliver these 说明书包括重要的安装、保养及清洁方面的内容，...
- Page 2 OPERATING INSTRUCTIONS 使用说明 When approaching faucet, water LED on 人靠近龙头，龙头上方显示屏将会 screen above the faucet will auto flash. 自动闪烁出水显示灯。 Place both hands under the faucet within 双手伸到出水口下方感应范围内，龙 the sensing range, water will outflow 头开始出水。同时龙头上方显示屏会 from the faucet. Meanwhile, soap LED 闪烁皂液灯，提示可以挥手取皂液。 on the screen above the faucet will light up indicating waving hand for soap solution.
-
Page 3: Rough-In Dimensions
安装尺寸 ROUGH-IN DIMENSIONS 艾非皂液感应龙头 艾非皂液感应龙头 AVID DUO SENSOR FAUCET AVID DUO SENSOR FAUCET （交流电/冷热混合型） （交流电/单冷型） (AC, MIXOR) (AC, COLD) 完成墙面 完成墙面 Finish the wall Finish the wall 123 151 123 151 50.5 50.5 开关 开关 Switch Switch (建议尺寸) (建议尺寸) (建议尺寸) (建议尺寸) (建议尺寸) Recommended Size... -
Page 4: Technical Specification
TECHNICAL SPECIFICATION 220V 50/60Hz Power: AC 220V, 50/60Hz Senser Duration: Less than 0.5s Shut-off Delay: 0.5~1s 0.5～1 Sensing Distance: Automatic adjustment Flow Rate: 0.5GPM (About 1.9L/min ) 0.5GPM 1.9L/min Overtime Flowing Control: Automatically stop flushing when the faucet senses an object for more than 1 minute continuously 1 ～40 Ambient Temperature: 1~40... - Page 5 注意： Note: Ensure cylinder install on water inlet. 三 安装皂液器 3. Install soap dispenser 94.3 1. 在墙壁合适的位置钻孔，打入膨 1. Drill the mounting holes properly, place 11.3x2 胀管，再用螺钉将皂液器支架固定 expansion tube, and then mount the soap Fig.1 在墙壁上（见图1）。 dispenser on the wall by screws (Fig.1). 图1 94.3 2.
- Page 6 5. Connect power supply and control 五 连接电源和控制线 wire 1. 将龙头电源线与控制盒对应接头 1. Connect and tighten faucet wire to corresponding connector on control box 连接并插紧（见图4）。 (Fig.4) . Fig.4 2. 将皂液器电源线与控制盒对应接 2. Align soap dispenser wire to 图4 corresponding connector on control box 头连接并插紧（见图5）。...
- Page 7 后，仍无合适水温，请再缓慢减少冷 capacity slowly until water temp is comfortable for use. 水出水量，直至水温使用舒适。 It is recommended to use Kohler TEE inlet hose assembly, 建议使用科勒推荐的三通进水软管 otherwise there is a risk of cold and hot water mixing 组件，否则有冷热水互窜的风险。...
-
Page 8: Installation Checklist
等，会对龙头表面造成伤害，切忌使用。 affect the surface and it is not recommended for cleaning. 有腐蚀性的清洁剂或溶剂不可使用于科勒的水龙 Do not use abrasive cleaners or solvents on Kohler faucets and fittings. 头及其配件上。 Do not wipe faucet with hard cleaning materials such as 不能使用百洁布、钢丝球等硬质清洁材料擦拭龙... -
Page 9: Important Consumer Information
IMPORTANT CONSUMER INFORMATION 1. Timeout setting When the faucet flows continuously for 1 minute, the 连续在感应状态下使用约一分钟，龙头自动止 faucet will automatically stop.Objects must be removed 水。自动止水后，手或物体离开感应范围后， from the sensing range. Then the water will flow when 再次进入感应范围内，龙头正常工作，否则 objects re-enter into the sensing range again. 无反应。... -
Page 10: Troubleshooting
Water runs for longer than Remove object Object in sensing range Clean residual water on the induction window 1 minute without switching off. Please contact with distributor or Kohler China Investment Co., Ltd., if the trouble remains after above-mentioned actions are taken. 1380339-T01-A... - Page 11 产品中有害物质含量的说明 回收提示 本产品超过使用期限或经过维修无法正常使用后，不应随意丢弃，请交由有废弃电器电子产品处理资质的 企业处理，正确的处理方法请查阅国家或当地有关废旧电器电子产品处理的规定。 有害物质统计表 有害物质名称 部件名称 六价铬 多溴联苯 多溴二苯醚 铅(Pb） 汞（Hg） 镉（Cd） (Cr(VI)） （PBDE） （PBB） × ○ ○ ○ ○ ○ 外壳组件 × ○ ○ ○ ○ 阀体组件 ○ ○ ○ ○ ○ 控制盒组件 × ○ ○ ○ ○ ○...
- Page 12 :Indicate only partial product series contains this substance. Note: the information provided is based on the supplier data and Kohler inspection results. The product is designed not to hurt the environment. Under current technology, all hazardous materials have been used in the smallest amounts possible. Kohler will strive to reduce the use of these hazardous materials used in this product.
