INSTALLATION INSTRUCTIONS

26040K-4

Single control lavatory faucet with drain

BEFORE YOU BEGIN

All information is based on the latest product information available at the time of publication. Kohler Co. reserves the right to make

changes in product characteristics, packaging, or availability at any time without notice.

Please leave these instructions for the consumer. They contain important information.

NOTES:

1. Flush the water supply pipe thoroughly to remove debris.

2. If possible, install this faucet before installing the lavatory

3. Inspect the supply tubing for damage and leakage. Replace and maintain as necessary.

4. Observe all local plumbing and building codes.

5. Shut off the water supply to the ﬁtting.

HANDLE OPERATION

Lift handle gently. Turn clockwise for hot water, turn counterclockwise for cold water.

ROUGH-IN DIMENSION

*Dimensions are approximate.

*Unit: mm

149

Note: The recommended dimension for installation can be adjusted according to user preferences and layout.

1436348-K2-A

Single control

lavatory faucet with drain

18°

100

Ø63

0~50

G1" 1/4

G1/2

BEAM

Need help?

Do you have a question about the BEAM 26040K-4 and is the answer not in the manual?

Page 1 Single control lavatory faucet with drain BEFORE YOU BEGIN All information is based on the latest product information available at the time of publication. Kohler Co. reserves the right to make changes in product characteristics, packaging, or availability at any time without notice.
Page 2 INSTALLATION How to Install the Spout Install the mounting stud(1) onto the bottom of faucet. Insert the faucet assembly into the lavatory hole. Position the faucet. From underside of the lavatory, place the bracket(2, Rubber washer is on the top) onto the mounting stud, and tighten the nut(3) to secure the faucet.
Page 3 All Finishes: Clean the ﬁnish with mild soap and warm water. Wipe entire surface completely dry with clean soft cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc, which could adversely aﬀect the ﬁnish and are not recommended for cleaning. Do not use abrasive cleaners or solvents on Kohler faucets and ﬁttings. 1436348-K2-A...
Page 4 3020026 Kohler (Thailand) also warrants all other aspects of the faucet or accessories (”Faucet”)** to be free of defects in material and workmanship during normal residential use for as long as the qriginal consumer purchaser owns his or her home. If a defect is found in normal residential use, Kohler (Thailand) will, at its election, repair, provide a replacement part or product, or make appropriate adjustment.
