ASSEMBLY INSTRUCTIONS
SKU: GAP
Description
Product Dimension : 18"Wx25"Dx36.3"H
Cube Size
Thank you for purchasing our product. This product has been designed for easy assembly and long-lasting use. Please take
the time to read and follow the assembly instructions carefully
GALLATIN PARSON CHAIR
: GALLATIN PARSON CHAIR
: 37.9"x19.6"x15.1"
BEFORE ASSEMBLY
- 1 -
175 Southbelt Industrial Dr,
Houston, TX 77047
Email:sales@eastwestfurniture.net
NW : 30.8 LBS
GW: 37.4 LBS
Advertisement
Table of Contents
Related Manuals for East West Furniture GALLATIN PARSON CHAIR GAP
Summary of Contents for East West Furniture GALLATIN PARSON CHAIR GAP
- Page 1 ASSEMBLY INSTRUCTIONS SKU: GAP 175 Southbelt Industrial Dr, Houston, TX 77047 Email:sales@eastwestfurniture.net Description : GALLATIN PARSON CHAIR Product Dimension : 18”Wx25"Dx36.3"H Cube Size : 37.9”x19.6”x15.1” NW : 30.8 LBS GW: 37.4 LBS BEFORE ASSEMBLY Thank you for purchasing our product. This product has been designed for easy assembly and long-lasting use. Please take the time to read and follow the assembly instructions carefully GALLATIN PARSON CHAIR - 1 -...
- Page 2 Be sure to check all packing material carefully for small parts that may have come loose inside the carton during shipment. Please separate, identify, and count all parts and metal hardware. Compare with the part list to be sure all parts are present. If the hardware is missing or you have difficulty assembling this product, please call for us.
- Page 3 HARDWARE LIST When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the following hardware: Description Sketch Description Sketch Long bolt Medium bolt (M6x70mm) (M6x60mm) ∅ ∅ Lock Washer Short bolt (M6x50mm) 6.5x...
- Page 4 STEP 2 Attach seat frame (B) to the chair back (A) by using bolts (3) and (1) and washers (4) and (5). Tighten with Allen Key (6). Note: DO NOT tighten any of the bolts until the chair assembled with all parts. STEP 3 Attach front legs (C) to the seat frame.
- Page 5 STEP 4 Place the chair on a flat level surface to make sure the chair is level and then tighten all bolts. STEP 5 Attach the bottom cover (removed on step 1) back on the seat frame and finish the assembly. GALLATIN PARSON CHAIR - 5 -...
