ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM1738F-1/2/3
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 5
(Included)
(Not Included)
Rev: 18-09-14
Advertisement
Related Manuals for Furniture of America CM1738F-1
Summary of Contents for Furniture of America CM1738F-1
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM1738F-1/2/3 ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Bolt Ø1/4" x 3-1/8" Headboard Bookcase #2 x 1pc #B x 8pcs Barrel Nut Ø1/4"...
- Page 4 Exploded View Insert barrel nuts (#B) to the side holes of the side rails (#3). Align side rails (#3) to the holes of the headboard (#1) and footboard (#2), then secure by tightening bolts (#A) onto barrel nuts (#B). #A x 8pcs #B x 8pcs Page 4 of 5...
- Page 5 Align support legs (#6) to the slat (#5), then secure by using screws (#D). Adjust the bottom levelers on the support legs (#6) according to ground level. #D x 3pcs Align slats (#4) to the side rails (#3) and center slat (#5), then secure by using screws (#C).
