MODEL #
CM1746T/F
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Phillips
Screwdriver
(Not Included)
3 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM1746T
Summary of Contents for Furniture of America CM1746T
- Page 1 MODEL # CM1746T/F Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Phillips Screwdriver (Not Included) 3 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 12...
- Page 5 DAYBED CM1746F/T #1 2pcs #2 1pc #4 1pc #3 2pcs Top Back Top Side Rails Arm(L&R) Bottom Front Panel Panel #5 1pc #6 2pcs #71Set(13pcs) 1Set(12pcs) Bottom Side Bottom Back Slats Up Slats Down Panels (Narrow) Panel 4pcs Top Centre Wood Top Centre Wood Plastic feet Supportor(Long)
-
Page 6: Exploded View
#D 20pcs #E 16pcs #F 4pcs Flat Washer Flat Washer Spring Washer 5/16" 5/16" 5/16" #G 75 pcs #H 4pcs #I 1pcs Screw #8X32mm Screw #8X50mm Allen Wrench 5mm Exploded View #1(L) #1(R) 48.8329 6 / 12... - Page 7 CM1746T/F is packed in 2 cases Carton Disignation Part Hardware #A x 8pcs Arm （ L&R) #B x 4pcs #C x 8pcs #D x 20pcs #E x 16pcs Slat Up CM1746T/F-1 #F x 4pcs #G x 75pcs #H x 4pcs...
- Page 8 ASSEMBLY INSTRUCTIONS Align legs (#9) to arms (#1), then secure by using screws (#H). There may not be pre- drilled holes. Part #1 x1pcs Part #9 x2pcs Hardware #H x2pcs Part #3 x2pcs Hardware #A x8pcs #E #D #A Hardware #D x8pcs Hardware #E x8pcs...
- Page 9 ASSEMBLY INSTRUCTIONS Part #10 x1pc Align and hook support (#10) onto the arms. Part #2 x1pc Hardware Align back (#2) to the arms, then #B x4pcs #F #D #B secure by using bolts (#B) with Hardware #D x4pcs washers (#D,F). Hardware #F x4pcs 9 / 12...
- Page 10 ASSEMBLY INSTRUCTIONS Align slats (#7) to the side rails, then secure by using screws (#G). Part #7 x1set Hardware #G x39pcs #E #D #C Align trundle panels (#4,5,6) as shown in the diagram, then secure Part #4 x1pc by using bolts (#C) with washers Part #5 x1pc (#D,E).
- Page 11 ASSEMBLY INSTRUCTIONS Align and hook support (#11) to the side trundle panels. Part #11 x1pc # 11 Align slats (#8) to the side rails, Part #8 x1set then secure by using screws Hardware (#G). #G x36pcs 11 / 12...
- Page 12 ASSEMBLY INSTRUCTIONS 12 / 12...
