- Page 1 Window Air Conditioner User Manual Model FWAC08M18 FWAC10M18 FWAC13M18 FWAC19M18 使用或安裝本產品前，請仔細閱讀本說明書，及所有安全注意事項， 並請妥善保存，以備日後參考查閱。 Before operating or installing the appliance, please read this manual and all the safety instructions thoroughly and retain it for future reference.
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTION ..............2 PARTS DESCRIPTION ..............5 OPERATION INSTRUCTION ............6 INSTALLATION INSTRUCTION ............10 TROUBLESHOOTING ..............13 SPECIFICATIONS ................14 WARRANTY ..................15 Read This User Manual You can find many helpful information on how to use and maintain the air conditioner properly. Just a little preventive care on the parts can extend the life of the air conditioner. Read the troubleshooting tips before call the service centre. -
Page 3: Safety Instruction
SAFETY INSTRUCTION Please follow below instructions to prevent injury and property damage. Meanings of symbols in this user manual. Never do this. Always do this. WARNING Do not put the power cord near Close the door while the Do not damage or use an flammable gas or combustibles, such unspecified power cord. - Page 4 ! CAUTION When remove the air filter, Ventilate the room well when Do not clean the air do not touch the metal parts used together with a stove, conditioner inner with water. of the unit. etc. It may cause an injury. An oxygen shortage may occur.
- Page 5 SAFETY INSTRUCTION Before operation 1. Contact an installation specialist for installation. 2. Do not use a damaged or non-standard power cord. 3. Do not share the same outlet with other appliances. Usage 1. Exposure to direct airflow for a long period of time could be hazardous to the health.
-
Page 6: Parts Description
PARTS DESCRIPTION NOTE: The front panel and cabinet may be slightly different according to the models, but the functions are the same. The following illustration is for explanation purpose only, the actual shape of the machine may be slightly different. 1. -
Page 7: Operation Instruction
OPERATION INSTRUCTION Control Panel The control panel will look like the following: Types 7200~8800Btu/h Type 12000~18000Btu/h AUTO SWING THERMOSTAT SELECTOR AUTO SWING COOLER COOL HIGH COOLER HIGH COOL COOL COOL HIGH HIGH COOL TEST MODE COOL TEST MODE SELECTOR THERMOSTAT PLEASE WAIT THREE MINUTES BEFORE RESTARTING PLEASE WAIT THREE MINUTES BEFORE RESTARTING NOTE: The outline of the operation panel is based on typical model, the function is same with the actual... - Page 8 OPERATION INSTRUCTION THERMOSTAT Thermostat The thermostat is used to set the desired room THERMOSTAT temperature when the unit is being operated in the COOL MODE. To set the desired room temperature, rotate the COOLER thermostat knob to the desired setting. After the set temperature is achieved the thermostat will automatically start and stop the compressor in order to maintain the desired set temperature.
- Page 9 Vent Control The vent control is located above the control panel. The operation method is different on different models (see the following figures). For maximum cooling efficiency, CLOSE the vent. This will allow internal air circulation. OPEN the vent to discharge stale air. CLOSE OPEN CLOSE...
- Page 10 Air Filter How to remove the air filter 1. Hold the tabs under the front panel, then uplift it outwards, and remove the front panel. 2. Pinch the handle under the air filter and make the air filter arched, remove it from the slot from underside to upside. 3.
-
Page 11: Installation Instruction
INSTALLATION INSTRUCTION Select the best location AWNING AWNING FENCE FENCE About 10mm About 10mm Over 50cm Over 50cm 1. To avoid vibration and noise, make sure the unit is installed securely and firmly. 2. Install the unit where the sunlight does not shine directly. If the unit is installed under direct sunlight, build an awning to shade the cabinet. - Page 12 Installation of the Cabinet NOTE: UNIT CAN BE SUPPORTED BY A SOLID FRAME FROM BELOW OR BY A HANGER FROM A SOLID Step 1 OVERHEAD SUPPORT. Remove the air conditioner from the package, remove fixing FLASH OR SEAL AROUND EXTERNAL screws and slide the air conditioner out from the cabinet (Refer WALL FRAME OR ARCHITRAVE to Installation Steps).
- Page 13 Installation Steps Step 1. Remove the front panel and the air filter 1. Hold the tabs under the front panel, then uplift it outwards, and remove the front panel (See Fig.1). 2. Pinch the handle under the air filter and make the air filter arched, remove it from the slot from underside to upside (See Fig.2).
-
Page 14: Troubleshooting
TROUBLESHOOTING Please review the chart first before you call for service. Normal Operation You may hear a pinging noise caused by water being picked up and thrown against the condenser on rainy days or when the humidity is high. You may hear the thermostat click when the compressor turns on and off. Water will be collected in the base pan during high humidity or on rainy days .The water may overflow and drip from the outdoor side of the unit. -
Page 15: Specifications
SPECIFICATIONS BODY DIMENSION(mm) WIRING SIZE TYPES(Btu/h) (W x H x D) (mm ) 450x346x585 ≥3*1.0 ≤9000 600x380x560 ≥3*1.5 > 9000 and ≤12000 660x428x680 ≥3*2.5 ≥18000... -
Page 16: Warranty
WARRANTY The product has 3 years warranty from the date of purchase. The warranty shall not apply: A. to any product subjected to misuse, alteration, act of God, improper handling, improper transport, improper testing or unauthorized repair; B. to cosmetic problems or defects which result from normal wear and tear under ordinary use yet not affecting the performance or use of the product;... - Page 17 安全注意事項 產品零件介紹 操作說明 安裝說明 疑難小百科 規格表 保用期資料 本使用說明書提供了許多有關冷氣機正確使用與維護的實用提示。衹要稍加注意，就 能延長冷氣機的使用壽命。在疑難小百科中，您可以找到許多常見問題的解法方法。 聯絡維修中心前，請先瀏覽疑難小百科。 請聯絡授權的技術人員進行維修或保養本產品 。 請聯絡授權的技術人員安裝本產品 。 除非有安全人員的指導或協助下 ， 並確保使用者的安全 ， 否則此冷氣機不可由兒童 、 精神病人 、 殘疾人士及反應過慢之人士使用 。 切勿讓兒童把玩冷氣機 。 電源線袛能由廠方授權的技術人員或同權合資格的技術人員進行更換 ， 以免發生意外 。 清潔或保養前，請先關掉電源與供電斷路器 。...
- Page 21 2 ( ≤ 12000Btu ) ( ≥ 18000Btu )
- Page 22 7200~8800Btu/h 12000~18000Btu/h AUTO SWING THERMOSTAT SELECTOR AUTO SWING COOLER COOL COOLER HIGH HIGH COOL COOL COOL HIGH HIGH COOL TEST MODE COOL TEST MODE SELECTOR THERMOSTAT PLEASE WAIT THREE MINUTES BEFORE REST ARTING PLEASE WAIT THREE MINUTES BEFORE REST ARTING ,各型號的選擇旋鈕會以下圖所示說明為準。...
- Page 23 製冷模式 THERMOSTAT COOLER 製冷設定 的製冷設定 製冷設定 TEST MODE 的製冷設定 在冷氣機製冷運行期間 AUTO SWING 製冷效果...
- Page 24 在製冷狀態下 的製冷效果 並關 濾塵網 濾塵網...
- Page 25 並 並...
- Page 26 製冷性能 佈...
- Page 27 並 並 位於 200 *...
- Page 28 掛...
- Page 29 疑難小百科 聯絡維修中心前請先看看下表 。 髒 冷氣機 製冷不夠 溢...
- Page 30 450x346x585 ≥3*1.0 ≤9000 600x380x560 ≥3*1.5 > 9000 ≤12000 660x428x680 ≥3*2.5 ≥18000...
- Page 31 保用期資料 由購買日期計正常使用下提供三年保用。 保用不包括下列各項: 產品錯誤使用、被更改、天災、因運輸拆卸不當、錯誤測試或不合格維修; 在正常使用情況下產生的正常損耗導致外觀問題或瑕疵而不影響產品功能; 如產品被拆開或更改; 產品的包裝、運輸費及出入口關稅或任何相關費用 在保用期內，所有正常使用下損壞的電器之檢查、維修及零件費均會獲得豁免。免費更換 的零件並不包括以下項目： • 各類隔塵網、外殼、塑膠附件及配件 • 非家庭使用或非個人用途之貨品 請妥善保存產品購買發票/單據。必須出示產品購買發票/單據方可獲三年保養服務。 如需要任何維修服務，請聯絡豐澤維修服務部 電話：2555-5788 注意事項 本產品必須插在或連接 220-240V 的專用插座, 並確保插頭完全插入插座後方能使用。切勿使用萬能 插座及延長電源線。 本產品屬高耗電量電器，不應與其他高耗電量電器共用插座。 此產品只作一般家庭用途。 環境保護 本產品使用壽命結束時請勿與一般家庭廢棄物一併丟棄。請將該產品放置於政府指定 的回收站。此舉能為環保盡一份心力。 重要信息 儘管本公司或其生產商受知會，在任何情況下本公司或其生產商將不須就任何聲明、承諾及保證 的索償而負責及不會向客戶或第三方承擔任何因使用或未能使用此產品所帶來直接的、非直接 的、非專業的、特殊的、偶然的、間接的、有代表性的或其他任何損傷的責任(包括但不限於身 體的損傷、財產的損失、公司盈利的損失、公司運作受中斷)。在任何情況下本公司或其生產商 所承擔之責任將不會超過此產品之購買金額。 。 產品如有任何技術規格更改不作另行通知...
- Page 32 16120300A06783...
