4.2 ESP32-DevKitC
4.2 ESP32-DevKitC
4.2.1 Overview
ESP32-DevKitC is a low-footprint, minimal system development board which is powered by our latest ESP-
WROOM-32. The dimensions of the board are shown in Figure 18.
18.0 mm
All pins of ESP-WROOM-32 are led out to the pin headers on both sides for easy interfacing. ESP32-DevKitC
features all the functions that are supported by ESP32. Users can connect these pins to peripherals as needed.
The interfaces are shown in Figure 19. For more details, please see Section
tion.
Espressif Systems
48.2 mm
55.0 mm
Figure 18: Top view of ESP32-DevKitC
3V3
EN
SVP
SVN
IO34
IO35
IO32
IO33
IO25
IO26
IO27
IO14
IO12
GND
IO13
SD2
SD3
GND
5V
Figure 19: ESP32-DevKitC Pin Layout
26
4 HARDWARE DEVELOPMENT
27.9 mm
4.1.2
ESP-WROOM-32 Pin Defini-
GND
IO23
IO22
TXD0
RXD0
IO21
GND
IO19
IO18
IO5
IO17
IO16
IO4
IO0
IO2
IO15
SD1
SD0
CLK
ESP32 Hardware Design Guideline V1.0
