Box Includes - FG 80F-POE Series
- PoE
1
FortiGate
1
LOGO
Green: The device is on
Off: The device is off
2
Green: Both power supplies are functioning
PWR
Amber: One power supply is functioning
Off: Power is off
Green: Operating normally; BLE is off
STATUS
Flashing
Flashing Amber:
Green: Operating in an HA cluster
HA
Amber: HA failover
Off: Not in an HA cluster
3
Flashing
SFP/WAN
(WAN & SFP
Off: No link established
are Shared Ports)
Red: Providing Max PoE Power, 96W
4
MAX PoE
Off: PoE power available
5
Ports
Green: PoE power on
PoE
Off: PoE power off
Flashing
LINK/ACT
Off: No link established
6
BLE/RESET Activates BLE management or restores to factory default
14
PoE
STATUS
SFP1
WAN1
1
2
3
4
5
6
A
B
PoE
LINK/ACT
PWR
HA
SFP2
WAN2
MAX
PoE
2
3
4
5
Green: Booting up
BLE is on
Green: 1000M/100M/10M data activity
Green: 1000M/100M/10M data activity
Box Includes - FWF 80F-2R Series
2R
BLE / RESET
6
(not included, sold separately)
80F
STATUS
1
3
5
A
WAN1
SFP1
HA
POWER
WiFi
2
4
6
B
WAN2
SFP2
FortiWiFi-80F-2R/81F-2R
QuickStart Guide
Power Cable
Ethernet Cable
Wall Mount Kit
(not included, sold separately)
BLE / RESET
12V DC Power Adapter
3x Antennas
Wall Mount Hardware
15
