Fortinet FortiGate Series Quick Start Manual page 11

Front Panel - FWF 81F-2R-POE
81F
2R-PoE
1
FortiWiFi
1
LOGO Blue: The device is on
Off: The device is off
2
WIFI
Green: WiFi connected
Flashing
Off: WiFi is off
Green: Operating normally; BLE is off
STATUS
Flashing
Flashing
Green: Both power supplies are functioning
PWR
Amber: One power supply is functioning
Off: Power is off
Green: Operating in an HA cluster
HA
Amber: HA failover
Off: Not in an HA cluster
3 Flashing
SFP/WAN
(WAN & SFP
Off: No link established
are Shared Ports)
4 Red: Providing Max PoE Power, 96W
MAX PoE
Off: PoE power available
5
Green: PoE power on
Ports
PoE
Off: PoE power off
Flashing
LINK/ACT
Off: No link established
6
BLE/RESET Activates BLE management or restores to factory default
20
PoE
WiFi STATUS SFP1 WAN1 1 2 3 4 5 6 A B
PoE
LINK/ACT
PWR HA SFP2 WAN2 MAX
PoE
2 3 4 5
Green: WiFi activity
Green: Booting up
Amber: BLE is on
Green: 1000M/100M/10M data activity
Green: 1000M/100M/10M data activity
1. Place the unit on a flat, clean and stable surface
2. Ensure there is at least 1.5in of clearance for adequate airflow
BLE / RESET
6
3. Plug the provided power cable into the rear of the unit and then into a
grounded electrical outlet or separate power source
Fortinet carries a variety of standard and custom rack and rail mount
accessories, including a rack mount tray kit, SP-RACKTRAY-02.
Ordering: Contact Fortinet to order brackets, rail slide kits, rack mount kits
and other accessories, such as a console cable
Desktop Option
1.5in
1.5in
1.5in
1.5in
Rack/Rail Mount Option
SP-RACKTRAY-02
21
