Additional Setup Options - Fortinet FortiGate Series Quick Start Manual

Additional Setup Options

Set up your Fortinet device locally or connect using forticloud.com
GUI
1
2
Port 1
Ethernet Cable
Note: For static IP configuration, use 192.168.1.1 with subnet mask
255.255.255.0
CLI
1
USB Console Cable
(available for purchase)
Console Port
Note: For a detailed CLI guide, visit
FortiGate Cloud Key
(Connect a WAN port to the Internet)
1
Go to forticloud.com and login with your FortiCloud Credentials or Register
2
Follow the on-screen instructions, then click Add FortiGate
3
Enter the FortiGate Cloud Key located on the sticker of your device
3
Management Computer
Speed (default): 9600
3
Data bits: 8
2
Stop bits: 1
Parity: None
Flow Control: None
Management Computer
docs.fortinet.com
Box Includes - FG 80F Series
Power Cable
Wall Mount Kit
(not included, sold separately)
8
FortiGate 80F/81F/Bypass
QuickStart Guide
12V DC Power Adapter
Ethernet Cable
Wall Mount Hardware
(not included, sold separately)
9
