Furniture of America CM-AC6900 Assembly Instructions

Download this manual

Assembly Instructions

CM-AC6900

ASSEMBLY RATING

Tools Required for Assembly:

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

Allen Wrench

(Included)

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

DIFFICULT

EASY

Page 1 of 5

Rev.14-10-31

Need help?

Do you have a question about the CM-AC6900 and is the answer not in the manual?

Page 1 Assembly Instructions CM-AC6900 ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
Page 2 Page 2 of 5...
Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Hardware List Parts List #A x 4 pcs #1 x 2 pcs Bolt 1/4”x5/8” Leg Stand #B x 10 pcs #2 x 2 pcs F/H Bolt 1/4”x5/8”...
Page 4 Insert the center stand support (#2) onto the 2 leg stands (#1). Turn right (clockwise) to tighten #A x 4 pcs Insert 4 bolts (#A) through the center stand support (#3) and secure those bolts using the Allen wrench (#C) to lock them with the 2 leg stands (#1).
Page 5 Turn right (clockwise) to tighten #B x 4 pcs Align the 2 upper stand supports (#2) with the pre- drilled holes of the assembled leg stands (#1). Insert 4 flat-head bolts (#B) through the 2 upper stand supports (#2) and secure those flat-head bolts using the Allen wrench (#C) to lock them with the assembled leg stands...
