Specifications - Altronix VertiLine16C Series Installation Manual

Altronix VertiLine CCTV Rack Mount Power Supplies provide 16 power outputs in a space saving 1U EIA 19"
rack mount chassis which may be rack, wall or shelf mounted. The units feature individually selectable 24VAC
and/or 28VAC power outputs with surge suppression. VertiLine CCTV Rack Mount Power Supplies are also
available in eight (8) and twenty-four (24) output models with various power ratings.
Input:
• 115VAC 60 Hz.
Output:
• Sixteen (16) individually selectable 24VAC
or 28VAC power outputs with OFF position.
• Sixteen (16) external blade fuse or
PTC protected outputs.
• Surge suppression.
Features:
• Sixteen (16) power LED indicators.
• Removable terminal blocks with locking
screw flange.
Sixteen (16) Output Rack Mount Configuration Reference Chart:
Output
Altronix Voltage
Model Number (VAC)
24VAC or
VertiLine16C
28VAC
24VAC or
VertiLine16CD
28VAC
24VAC or
VertiLine166C
28VAC
24VAC or
VertiLine166CD
28VAC
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or mois-
ture. This installation should be made by qualified service personnel and should conform to
the National Electrical Code and all local codes.
- 2 -
Overview:

Specifications:

10A 16 Fused
10A 16 –
14A 16 Fused
14A 16 –
Features (cont'd):
• Illuminated master power disconnect circuit
breaker with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
Mechanical:
• Units can be rack, wall or shelf mounted.
• Modular 1U standard EIA 19" rack mount chassis
• Enclosure Dimensions (H x W x D approx.):
1.625" x 19.125" x 8.5"
(41.3mm x 486mm x 216mm).
– 3A 3A
10A 3A
PTC 2.5A - -
– 3A 3A
15A 4A
PTC 2.5A –
Agency UL Listings and
Listings File Numbers
UL Listed for
Commercial
CCTV Equipment
(UL 2044).
CUL Listed - CSA
Standard
C22.2 No.1-04,
Audio, Video and
Similar Equipment.
Vertiline16C Series Installation Guide
