Summary of Contents for EcoxGear ECOSTONE GDI-EGST700
- Page 1 Quick Start USER GUIDE ECOSTONE Features & Operation Models: GDI-EGST700--710 QUICK START 1-2-3 STEP 1: Power ON your ECOSTONE STEP 2: SEARCH your Bluetooth Connection on your Smart-device STEP 3: PAIR & PLAY STANDBY SPEAKER TRACK PLAY PAUSE BLUETOOTH ON/OFF VOLUME SELECTION ANSWER...
-
Page 2: Set Up Recommendations
Quick Start USER GUIDE STEPS 1-2-3 Set Up Recommendations STEP 1 CHARGE your ECOSTONE Before you power on your ECOSTONE connect the USB Micro port to the USB cable and a power source to fully charge your ECOSTONE for best performance. NOTE: Before using your ECOSTONE for the first time, charge the unit until all 4 LED battery level indicators are solid green, indicating a full charge. - Page 3 Turn on Bluetooth on your Bluetooth device (Smart-device) and set the device in pairing mode. Available Bluetooth connections shall appear. Select the ECOXGEAR speaker from the list of discovered devices on your Bluetooth device. Wait for a few seconds until the connection is completed.
- Page 4 Quick Start USER GUIDE Control Buttons & Connections, Functions & Feature TOP PANEL [on the top] PRESS the STANDBY POWER button to turn the ECOSTONE ON/OFF. When turned OFF the ECOSTONE remains in STANDBY POWER mode. STANDBY IMPORTANT: Standby Power function will NOT operate when the ON / OFF MASTER POWER is set OFF.
-
Page 5: Back Panel
Quick Start USER GUIDE BACK PANEL Master Power Switch & Connections [under the Cap] To access the connections TURN the cap to the LEFT so the cap’s arrow point lines up with “UNLOCKED” along the back edge of the unit. STEP 1: Select “UNLOCKED”... - Page 6 Quick Start USER GUIDE BACK PANEL [under the Cap] Master Power Switch & Connection Functions MASTER POWER ECOSTONE has a separate Master Power Switch and a Standby Button. ON OFF The Switch MUST be set to the ON position to power your ECOSTONE. MASTER Once the Switch is set to ON, use the Standby Button located on the top panel to turn the unit ON/OFF POWER...
- Page 7 Quick Start USER GUIDE BACK PANEL [CAP CLOSED & LOCKED] IMPORTANT IF the cap on the back panel is not properly closed, the unit is NOT watertight. To ensure the unit is watertight & waterproof, ALWAYS CLOSE the CAP PROPERLY TURN the cap to the RIGHT so the cap’s arrow point lines up with...
-
Page 8: Bottom View
Quick Start USER GUIDE BOTTOM VIEW: ¼” attachment point for use with FRONT VIEW: carrying handle & grill tripod stand or suction cup mounts (available separately) SPECIFICATIONS Unit Size / Weight: 3.8” x 12.3” x 7.0“ / 41 ounces Mount Attachment Point: 1/4"... -
Page 9: Fcc Statement
FCC STATEMENT: This device complies with Part 15 of the FCC Rules. Operation is subj e ct to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. - Page 10 Read and Follow all Instructions. Use only as intended. The ECOXGEAR Bluetooth speaker is intended to be used indoors or outdoors and in land or water environments. The speaker has been tested to IPX7 waterproofing standards which means the speaker can be submerged in water up to 3 feet of water for 30 minutes without any damage.
- Page 11 6) Completely dry and clean your ECOXGEAR prior to attempting to charge the unit. 7) Return the ECOXGEAR to Grace Digital if you suspect water ingress into the unit or if the unit has experienced a severe impact that may have affected the integrity of the unit to take on water.
-
Page 12: Care, Maintenance & Precautions
ECOSTONE by ECOXGEAR, a division of Grace Digital Inc., San Diego, California. Visit us on Facebook ECOSTONE by ECOXGEAR, a division of Grace Digital Inc. Designed in California, Assembled in China. All rights reserved. The Trademark BlackBerry® is owned by Research In Motion Limited and is registered in the United States and may be pending or registered in other countries.
