LBT30-MO
9281 LeSaint Drive • Fairfield, Ohio 45014
Phone (513) 874-2818 • Fax (513) 874-2914
Sales: 1-800-543-7166
T30 HydroSeeder
Parts and Operator's Manual
Model MO
Serial No.
Activate
Activate
Your Warranty
Your Warranty
By Registering
By Registering
TODAY!!!
TODAY!!!
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T30 HydroSeeder MO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Finn T30 HydroSeeder MO

Summary of Contents for Finn T30 HydroSeeder MO

  • Page 1 Activate Activate Your Warranty Your Warranty By Registering By Registering TODAY!!! TODAY!!! 9281 LeSaint Drive • Fairfield, Ohio 45014 Phone (513) 874-2818 • Fax (513) 874-2914 Sales: 1-800-543-7166 T30 HydroSeeder ® Parts and Operator’s Manual Model MO Serial No. LBT30-MO...
  • Page 2 NOTES...
  • Page 3 IF FINN CORPORATION DOES NOT HAVE YOUR COMPLETED REGISTRATION FORM ON FILE, YOUR WARRANTY CLAIM WILL BE DENIED. Once your FINN equipment has been registered, your FINN Limited Warranty will be activated per the warranty statement on the next page.
  • Page 4 Follow the instruction sheet, on property damage sustained by a person claiming to be a third party how to use your Finn Oil Analysis Kit that comes with the Kit. Failure beneficiary of a surviving warranty under the law of any jurisdiction.

  • Page 5: Table Of Contents

    Definition of Hydroseeding ........6 The FINN HydroSeeder® And How It Works..... . . 6 Towing Vehicle .
  • Page 6 INDEX Troubleshooting your HydroSeeder ® ......25–29 Leaks..........27 Machine Jumps During Operation .

  • Page 7: Safety First

    SAFETY FIRST With any piece of equipment, new or used, the most important part of its operation is SAFETY! FINN Corporation encourages you and your employees to familiarize yourselves with your new equipment and stresses safe operation. The first five pages of this manual are a summary of the main safety aspects associated with this unit.
  • Page 8 Practice all other usual and customary safe working precautions. Above all, remember that safety is up to you. The FINN HydroSeeder® is designed to mix and apply water, seed, fertilizer, agricultural lime, and hydraulic mulch to the prepared seedbed. The resultant slurry from mixing one or more of the above materials may react, causing harmful or deadly gasses within the tank.
  • Page 9 5. The driver of the carrying or towing vehicle is respon- 2. Never engage (turn on) sible for the safety of the operator(s) of the machine. clutch when both Make sure the driver is aware of and avoids all recirculation dis- possible hazards to the operator(s) of the machine, charge valves are closed.
  • Page 10 (29 CFR 9. It is recommended that only authorized, genuine 1910.147). FINN replacement parts be used on the machine. Provide continuous ventilation or proper breath- ing apparatus. 10. Do not use either cold start fluid, if engine is...
  • Page 11 CURRENT SET OF SAFETY DECALS WA R NING B U R N H A Z A R D ! C ontents c ould be under pres s ure. DO NOT c ome in c ontac t with material. E ns ure material in line is not hot before loos ening c lamps or opening valves .

  • Page 12: Definition Of Hydroseeding

    THE FINN HYDROSEEDER ® AND HOW IT WORKS The FINN HydroSeeder ® will apply seed, fertilizer and/or lime, fiber mulch, or stabilizing materials in any prescribed or desired combination. The materials placed in the HydroSeeder ® slurry tank...

  • Page 13: Mounting The Hydroseeder

    U-bolts. NOTICE Mounting the HydroSeeder® to the truck must allow for tire clearance and frame twist. Place hard wood spacers along the length of truck rails or use FINN spring-mounting kit (part number 011562) or equivalent. CAUTION When using a truck with a tilt bed, be sure to chain the truck bed down to prevent the bed from being accidentally hoisted.

  • Page 14: Pre-Start Check

    2. Remove cap (Figure 1) and fill cap with sodium- (water sol- Grease Grease uble) base grease (FINN part number 000698). Do not use lithium-base (chassis lube) grease. 3. Replace cap. 4. Turn thumb nut (Figure 1) counterclockwise until thumb nut is at the top of the stem.

  • Page 15: Valve Operation

    IMPORTANT: When the thumb nut has moved down to within 1/2 in. (1.25 cm) of touching the cap, service the automatic pressure lubricator. 10. Check and clean the nozzles and hoses of any obstructions. 11. Check pump discharge, recirculation, and remote valve handles for free movement. VALVE OPERATION The base HydroSeeder ®...

  • Page 16: Starting Procedure

    The tables, on page 11, show loading versus coverage rates for the FINN T30. Table A shows rates for one-step applications. The coverage area is determined by the fiber mulch capacity of the HydroSeeder ®...
  • Page 17 TABLE A USING SEED, FERTILIZER, AND MULCH Unit Amount of Material in Tank in pounds (kilograms) Coverage Area Seed Fertilizer Mulch sq ft (sq m) 28 (13) 32 (15) 120 (54) 3,485 (324) Table is based on 1,500 lbs (680 kgs) of mulch, 400 lbs (181 kgs) of fertilizer, and 345 lbs (156 kgs) of seed at 8 lbs (3.6 kgs) / 1,000-sq-ft-per-acre.

  • Page 18: Tank Capacity Chart

    TANK CAPACITY CHART T-30 Gallons in. (cm) from in. (cm) from (Liters) bottom (1136) 6.25 (15.9) 32.75 (83.2) (1041) 8.75 (22.2) 30.25 (76.8) (946) (27.9) (71.1) (852) 13.5 (34.3) 25.5 (64.8) (757) (40.6) (58.4) (662) 18.25 (46.4) 20.75 (52.7) (568) 20.5 (52.1) 18.5...
  • Page 19 D. Open throttle to approximately 1/2 to 3/4 full. E. Engage (turn on) clutch. F. When discharge stream is clear, open recirculation valve and close discharge valve. After recirculation stream is clear, disengage (turn off) clutch. G. Replace coupler gasket in the remote valve coupler (or in boom on the platform option).
  • Page 20 LOADING AND MIXING BFM, FGM, SMM AND OTHER HIGHLY VISCOUS SLURRIES 1. With clutch disengaged (turned off) and agitator control in the NEUTRAL position, start engine and allow it to warm up. See STARTING PROCEDURE page 10. 2. Start filling unit with water from one of the water sources as listed below. When water reaches the top of agitator shaft, move agitator control to full REVERSE position.
  • Page 21 NOTE: BFM, FGM, and other viscous slurries will entrain air if proper mix- ing procedures are not followed. Ensure that the agitator blades are completely submerged prior to the addition of this material. This will prevent air from entering the slurry. Follow manufacturers sug- gested rates of materials as indicated on the packaging.

  • Page 22: Prior To Application

    PRIOR TO APPLICATION 1. Operator should familiarize themselves with the area to be seeded and develop a plan to ensure uniform application. 2. Develop a plan for communication between operator and driver of the carrying or towing vehicle to signal for start, stop, turn, etc. through the use of the signal horn. 3.

  • Page 23: Application Of Slurry

    APPLICATION OF SLURRY I. GENERAL APPLICATION TECHNIQUES DANGER Do not spray toward power lines, transformers or other high voltage conductors. Failure to comply will result in death or serious injury. CAUTION The driver of the carrying vehicle should remain alert for hazards to the operator, such as low power lines, hanging branches, etc.

  • Page 24: Procedure When Using Hoses

    II. PROCEDURES WHEN USING HOSES Always pump clear water through hose before pumping mulch. If the inside hose liner is dry, it will dewater the mulch, causing hose to plug. DISCHARGE THROUGH HOSE OR HOSE REEL WITH REMOTE VALVE 1. Open recirculation valve, close discharge valve, and close remote valve at the end of hose. 2.

  • Page 25: Cleaning And Maintenance

    CLEANING AND MAINTENANCE DAILY 1. Cleaning the HydroSeeder ® A. Fill slurry tank to center of agitator shaft with clear water. B. Move agitator lever to full speed to flush off inside of tank top and walls. C. Remove discharge nozzle and coupler gasket from remote valve coupler at the end of the discharge hose.

  • Page 26: Seasonal And Winter Storage Maintenance

    SEASONAL AND WINTER STORAGE MAINTENANCE 1. Drain slurry tank of all water prior to storage, and leave the drain plug uninstalled. 2. Park unit in suitable location and chock wheels to prevent inadvertent movement. 3. If possible, cover machine with tarp or park inside of an enclosure. 4.

  • Page 27: Lubrication And Fluids Chart

    LUBRICATION AND FLUIDS CHART Ref. No. Location Lubricant Frequency Number Check Grease Level in Automatic Pressure Lubricator Daily Grease Agitator Shaft Bearings Daily Check Engine Oil Level Daily Change Engine Oil and Filter See Engine Manual Grease Pump Bearings Weekly Check Hydraulic Fluid Level Weekly Change Hydraulic Fluid and Filter...

  • Page 28: Pump Assembly

    Suction Cover Washer 8 Locking Bolt Radial Lip Seal Lockwasher Casing Bearing Clutch Bearing Bolt Clutch Spacer Bearing Washer Pump Frame Frame Bearing Casing Drain Plug NOTE: See parts manual for FINN part number. 11LN 12LW Figure 6 – Pump Assembly Components...

  • Page 29: Hydraulic System

    The hydraulic oil filter must be replaced on schedule with a 5 absolute micron filter (FINN part number 023914). The hydraulic system relief is factory-set at 2,250 psi (15,513 kPa).
  • Page 30 C. CLEANING 1. To clean pump impeller (3), loosen the two Victaulic pipe clamps and remove suction pipe assembly. The eye of the pump impeller can then be seen through the pump suction cover (1) and is readily accessible for cleaning. 2.

  • Page 31: Troubleshooting Your Hydroseeder

    TROUBLESHOOTING YOUR HYDROSEEDER ® Because of the tremendous work load usually placed upon the HydroSeeder ® , minor malfunctions will occur from time to time. If not remedied immediately, they could lead to degraded performance and damage to the equipment. This section describes possible problems and the action to correct them. 1.
  • Page 32 C. Obstruction in pump can be indentified by a drop in pressure. If a drop in pressure is accom- panied by a frothy or whitish discharge stream, blockage is in suction line or sump area. To clear the pump: 1. Disengage (turn off) clutch and stop engine. Perform proper lockout/tagout proce- dures.

  • Page 33: Leaks

    ® TROUBLESHOOTING YOUR HYDROSEEDER Problem Probable Causes Suggested Solutions LEAKS: Tank Bearing Lack of lubrication – seal worn Replace seal and follow lube schedule. Bolts not tightened Tighten uniformly to 25 lb–ft (34 N•m). Pressure Pipe Clamps Rubber seal cracked, pinched, or Replace, always grease seal torn.

  • Page 34: Valve

    ® TROUBLESHOOTING YOUR HYDROSEEDER Problem Probable Causes Suggested Solutions VALVE: Valve stuck Frozen Thaw out ice and lubricate; leave in discharge position during stor- age. Constant plugging during operation Foreign material in slurry Drain and clean out tank; check storage for foreign materials. Constant plugging during loading Loading HydroSeeder®...
  • Page 35 HydroSeeder ® Parts Manual Model MO...
  • Page 36 WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT30-MO...

  • Page 37: Common Loose Parts

    COMMON LOOSE PARTS Ref. No. Part Number Description No. Required 085145 Hydraulic Reservoir 085262 Kohler 18 HP Gasoline Engine (See Page 42) 004593 Drain Plug 085265 Pump Isolator 035142 Fuel Tank 035123V Fuel Tank Shut-Off Valve 035123G Fuel Tank Shut-Off Valve Grommet F30-0009 Fuel Tank Strap 005495-22...
  • Page 38 WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT30-MO...

  • Page 39: Suction, Discharge, And Recirculation

    SUCTION, DISCHARGE, AND RECIRCULATION PIPING Ref. No. Part Number Description No. Required 085160 Clump Assembly (See Pages 34-35 for parts breakdown) 080366 Pipe Clamp 002439 Clamp Gasket 1 per 002868 90° Grooved Elbow 085210 Suction Pipe Weldment 008469 Discharge Pipe Gasket 080558-01 Discharge Pipe Weldment 005083-07...
  • Page 40 WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT30-MO...

  • Page 41: Clutch/Pump Assembly

    CLUTCH/PUMP ASSEMBLY Ref. No Part Number Description No. Required 085160 Clump Assembly 080489 Pump Suction Cover 0X0720 Pump Suction Cover Bolt 000Y07 Pump Suction Cover Nut 080499 O-ring 085159 Pump Impeller 080485 Mechanical Seal 080487 Pump Casing 0X0720 Suction Cover Bolt 000W07 Suction Cover Washer 080493...
  • Page 42 WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT30-MO...

  • Page 43: Hydraulic System

    HYDRAULIC SYSTEM Ref. No. Part Number Description No. Required 085247 Hydraulic Hose and Fittings Kit (Items 1–18) 012044 Pressure Gauge 012874 Straight Male Adapter 022301 Street Tee 023186 Straight Male Adapter 023616 Straight Male Adapter 023911 Straight Female Adapter 055230 Male 90°...

  • Page 44: Hydraulic Pump Drive Assembly

    HYDRAULIC PUMP DRIVE ASSEMBLY Ref. No. Part Number Description No. Required 0X0616 3/8-16 x 1" Lg. Hex Hd. Bolt 080642 Hydraulic Pump F30-0001 Hydraulic Pump Coupling Guard 080807 Coupling Half 5/8" Bore w/ Keyway 080809 Coupling Sleeve 080808 Coupling Half 1" Bore 190123-24 1/4"...

  • Page 45: Hydraulic Agitator Drive Assembly

    HYDRAULIC AGITATOR DRIVE ASSEMBLY Ref. No. Part Number Description No. Required 0X0824 1/2-13 x 1-1/2" Lg. Hex Hd. Bolt 080482 Hydraulic Motor F60-0022-02 Agitator Coupling Guard 00Y08L 1/2-13 Locknut 085128-01 Torque Arrestor Plate 080523 2-Piece Rigid Coupling 022657 Worm Gear Clamp (This is 4" Clamp) 085150 Torque Arrestor Pad WHEN ORDERING PARTS, BE SURE TO STATE...
  • Page 46 BEARING ASSEMBLY NOTE: To tighten, Turn nut not bolt. Torque to 25 lb ft (34 N m) 1-1/2" Agitator DO NOT OVER TORQUE Shaft Through Back Side NOTE: 085161-01 Rear Bearing Assembly 085161-02 Front Bearing Assembly (both include items #1 - 9) Outside Of Tank Wall...

  • Page 47: Agitator And Bearing Assembly

    AGITATOR AND BEARING ASSEMBLY Ref. No. Part Number Description No.Required 085161-01 Rear Bearing Assembly (Includes #1 thru #9) 085161-02 Front Bearing Assembly (Includes #1 thru #9) 085162-01 Rear Clamping Ring 1 per 085162-02 Front Clamping Ring 1 per 007416 Agitator Rotary Gasket 1 per 006975 Agitator Bearing Gasket...

  • Page 48: Engine Parts

    ENGINE PARTS Ref. No. Part Number Description No. Required 085262 Kohler 18 HP Engine KL4708303 Air Filter 080105 Fuel Filter KL1205001 Oil Filter KL2406817 Muffler 031421 Muffler Clamp 031420 Muffler Elbow NOT SHOWN 085142 Throttle Cable 080567 Choke Cable WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT30-MO...

  • Page 49: Hose Reel Parts

    HOSE REEL PARTS Ref. No. Part Number Description No. Required 085246 Electric Hose Reel Assembly (See Pages 48–49) 1 080261 Female Nyglass Coupler 003308-10 1-1/4" Hose x 100' F30-0005 Hose Reel Mount Tray 085252 Lead-In Hose 080378 Male Nyglass Coupler 020886 Push Button 080800...
  • Page 50 WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT30-MO...

  • Page 51: Hose Reel Assembly

    HOSE REEL ASSEMBLY Ref. No Part Number Description No. Required 085246 Electric Hose Reel Assembly 080801-6 Inlet Pipe 080801-14 Seal and Ring Assembly 080801-07 Snap Ring 080801-03 Bearing Housing Sub-Assembly 080801-10 Sprocket 080801-12 Chain Assembly 080801-08 O-ring 080801-11 Gooseneck 080801-09 RHP Ball Bearing 008188 Electric Motor...

  • Page 52: Control Panel Wiring

    (White) IGNITION (Red) SWITCH CLUTCH SWITCH CLUTCH (White) ENGINE PLUG CONTROL PANEL WIRING Ref. No. Part Number Description No. Required 085267 Control Panel Assembly 080654 Ignition Switch 080654-K Ignition Key 010531 Clutch Toggle Switch 080526 Clutch Toggle Switch Dust Boot 035084 Electric Clutch 085164...

  • Page 53: Tool Kit

    Narrow Fan Nozzle 080260 Male Nyglass Adapter 160750 Reducer Bushing 004593 Expansion Plug 006515 Coupler Gasket 012681A FINN Beige Aerosol Paint 012305 Adhesive Label (Remove Aerosol Can) 080535 Remote Valve Assembly 012083 Full Port Ball Valve 080260 Male Nyglass Adapter 080261...
  • Page 54 est Test Test Test Test Test Test Test Test Test. Hydro Seeder WHEN ORDERING PARTS, BE SURE TO STATE SERIAL NUMBER OF MACHINE LBT30-MO...

  • Page 55: Decals

    DECALS Ref. No. Part Number Description No. Required 080699 Decal Sheet 011690 FINN Nameplate 031235 Decal "FINN" 085158 Decal "T30 HydroSeeder" KL2511317 Decal "STOPPING INSTRUCTIONS" KL2411303 Decal "IGNITION SWITCH" 011662 Decal "U.S. Patent Numbers" 007230 Decal "Service Daily" 023519 Decal "CAUTION! Wear Eye Protection..."...
