I N S TA L L AT I O N G U I D E
mero CLose CoUpLeD toILet sUIte
150
s e i m a . c o m . a u
630
Please note
−
Installation shall be in accordance with AS/NZS3500.
−
All measurements are in millimetres. Height dimensions are to base of pan. Make allowance for bedding.
−
Bedding: Fix pan to floor using a sand cement mixture of 3:1 to a depth of 60mm. Do not use lime or fast-drying cement.
−
Bracket fixing: The pan should be bedded with an acetic cured silicone sealant and fixed with the brackets supplied.
−
Dimensions are nominal and subject to normal ceramic manufacturing variations.
−
Specifications may vary without notice as part of our continuous improvement practices.
−
Clean with a damp cloth. Do not use abrasive cleaners, liquids or pastes.
Ceramic close coupled toilet suite
White vitreous china
−
−
Soft closing seat
−
Suitable for S trap installations only
−
Right or left bottom entry plumbing
Suits bottom entry plumbing. Left and right bottom entry inlet points.
CISTERN
Close coupled with box flushing rim.
PAN
S trap installations only.
TRAPS
Soft closing.
SEAT
4 star rating 4.5/3 litre water saving flush.
WELS
150 mm.
SETOUT
This is a close coupled toilet suite — the cistern is fixed directly to the
FIxINg
pan and does not require wall fixing.
Pan may be bedded with cement base or using silicone sealant.
400
150
370
© Seima
mero-cc-in | v 2.0 | page 1 of 4
Advertisement
Table of Contents
Related Manuals for Seima MERO 191740
Summary of Contents for Seima MERO 191740
- Page 1 Specifications may vary without notice as part of our continuous improvement practices. − Clean with a damp cloth. Do not use abrasive cleaners, liquids or pastes. © Seima s e i m a . c o m . a u mero-cc-in | v 2.0 | page 1 of 4...
- Page 2 Cap is used to cover plastic plug. seat paCkage Contents 1 x seat and lid — soft closing 2 x plastic bolts For securing seat to pan. Page 2 of 4 | seima.com.au...
- Page 3 The white caps can be used to cover the plugs on each side of the pan. Important: Do not over-tighten the bolts or screws as this may cause the ceramic to crack and break. Page 3 of 4 | seima.com.au...
- Page 4 Cover tab — once the seat is secured, use the plastic cover tab to hide the bolt and hole. To fit seat — use the plastic bolts to secure the seat in place. Cover tab — clicked into place. Page 4 of 4 | seima.com.au...
