System Controller SCC-3100
Thank you for purchasing a Samsung System Controller.
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
User's Manual
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCC-3100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung SCC-3100

Summary of Contents for Samsung SCC-3100

  • Page 1 Perfect Control Solution System Controller SCC-3100 User’s Manual SALES NETWORK Thank you for purchasing a Samsung System Controller. SAMSUNG TECHWIN CO., LTD. TIANJIN SAMSUNG OPTO-ELECTRONICS CO., LTD. • • 145-3, Sangdaewon 1-dong, Jungwon-gu, Seongnam-si, 7 Pingchang Rd, Nankai Dist. Tianjin 300190, P.R China...

  • Page 2: Table Of Contents

    Contents 6. MODEL Safety caution 7. TRACE Major Functions and Features 7-1. TRACE Memory 1. Overview 7-2. TRACE Operation 2. Features Product Components 8. AF System Overview 9. OSD DVR Mode 1. System Connections CONTROLLER Mode 1-1. Connecting Controller and Junction Box 1.

  • Page 3: Safety Caution

    Safety caution Safety caution Caution Warning • All work related to the installation of this appliance must be performed by qualified • Use the appliance indoors only. - Do not place the appliance outdoors or expose it to rain or moisture. service personnel or system installers.

  • Page 4: Major Functions And Features

    Power Adaptor (DC 12V) User's Manual - It is possible to totally control the 255 Speed Dome camera, CCTV Receiver, Samsung Matrix and Samsung Digital Video Recorder. - If the Speed Dome is set to one-way reception (RESPONSE OFF), it is possible to connect a maximum of 16 subcontrollers, including the master controller.

  • Page 5: Connecting Junction Box And External Devices

    System Overview System Overview 1-2 Connecting Junction Box and External Devices 2. RS-485/422 Pin Layout (D_SUB_FEMALE) 3.RS-232C Pin Layout (D_SUB_MALE) [SVR-1630 connection] [PTZ connection] (SPD-3300/3000/2300, SPD-2500/2200/1600) [SVR-1650/1640/950/1630/430 connection] * RX+ and TX+ / RX- and TX- must be short- * RX+=DATA+ circuited.

  • Page 6: General Connection

    FUNCTION : Used to perform 2 functions or more at the same time (see p.11). connections allowed) : Controller Connection Cable : RS-485/422 • SVR-1630 cannot use general connection. : Video Cable Buttons supported by different manufacturers SAMSUNG PANASONIC SPD-3300 SPD-3000 SPD-2300 SPD-2500 SPD-2200...

  • Page 7: Number Pad

    CAMERA : Enter camera number and press the CAMERA button to set the camera ID : Used for increasing or decreasing menu values in (PTZ mode) or set the channel (DVR mode). detailed setup menus. MONITOR : Selects the MATRIX mode 4. Universal Controller PANASONIC SAMSUNG SPD-3300 SPD-3000 SPD-2300 SPD-2500 SPD-2200 SPD-1600...

  • Page 8: Dvr Controller

    Names and Functions of Each Part Names and Functions of Each Part Buttons supported by different manufacturers 5. DVR Controller SVR-1650 SVR-1640 SVR-950 SVR-1630 SVR-430 QUICK SET : The Quick Setup menu is displayed in the QUICK SET DVR monitor. STATUS STATUS : The current DVR status is displayed in the...

  • Page 9: Camera Controller

    [ Joystick ] without a master controller. • Always assign a unique ID to ensure that the controller IDs do not conflict with each other. 7. Junction Box • SPD : SPD-3300/SPD-3000/SPD-2300/SPD-2500/SPD-2200/SPD-1600(Samsung Techwin Co., Ltd.) [Front] [Back] 3. Camera ID Setup Enter a number using the number pad.

  • Page 10: Joystick/Camera Control Button

    PTZ CONTROL PTZ CONTROL 4. Joystick/Camera Control Button 5. SPEED DOME OSD Menu Control The joystick can be used to control the camera s left and right (pan) and up and down This is the ENTER/ESC button for SPEED DOME OSD (tilt) movements.

  • Page 11: Ptz Mode

    (see p.19). CAM ID: 3:CONTROLLER menu. PRESET NO: 0 Use the joystick or camera control button (SCC-3100 Press Numeric Key Enter:Preset ID Set model) to move the camera to the desired location (move up, down, left, and right, and control zoom).

  • Page 12: Swing

    • AUTO-SEQ and SCAN functions are performed when the • AUTO-PAN is performed automatically when the SWING button of PANASONIC(WV- GROUP button is pressed (for PANASONIC(WV-CS854A) CS854A) and SAMSUNG ELECTRONICS (SCC-641/643) cameras is pressed. and SAMSUNG ELECTRONICS (SCC-641/643 only). SYSTEM CONTROLLER User’s Manual...

  • Page 13: Tour

    PTZ Mode PTZ Mode 5. TOUR TOUR This menu is for setting one or more Groups for Tour so that continuous Group operations can be carried out. The TOUR SETUP menu is only available for an SPD series. GROUP 1 GROUP 2 GROUP 3 5-1.

  • Page 14: Model

    (tilt), zoom, and focus controls. 3300/3000/2300, SPD-1600/2200/2500, PELCO-D, PANASONIC(WV-CS854A) and SAMSUNG ELECTRONICS (SCC-643) types can be selected. Press the ENTER button to stop camera movement input. • Maximum length for movement memory is approximately 60 ~ 105 seconds. This may vary according to free memory space.

  • Page 15: Osd

    PANASONIC (WV-CS854A) - Toggle camera menu on/off (press CLR) Press the 1 button to automatically adjust the focus AF STOP SETUP Samsung (SCC-643/641) - Toggle camera menu on/off (press CLR) after camera operation. Press the 2 button to disable CAM ID:...

  • Page 16: Dvr Mode

    DVR Mode Controller Mode DVR MODEL Setup 1. Setup Mode This menu is for setting the DVR ID and model for At the initial screen, press the FUNCTION button and press SETUP SYSTEM SETUP SYSTEM operation by a controller. Sub-controllers cannot be 1:PTZ 2:DVR the 0 button to activate the [SETUP SYSTEM] menu.

  • Page 17: Id Setup

    Controller Mode Controller Mode 2. ID Setup 4. DATA COPY This menu is for setting controller ID. This menu is for copying master controller menu data to a sub-controller. The controller ID value is not copied. At the [Controller SETUP 1 ] menu, press the 1 button (see p.30). CONTROLLER SETUP1 At the [CONTROLLER SETUP 1 ] menu, press the 3...

  • Page 18: Response

    Controller Mode Controller Mode For information on camera RESPONSE settings (DIP switch settings), refer to the camera manual. 5. RESPONSE 5-1. SPD-3300/3000/2300 DIP Setup This menu is for setting RESPONSE function of the camera which is connected Controller. At the [CONTROLLER SETUP 1 ] menu, press the DIP-SW 1 RESPONSE Setup...

  • Page 19: Password

    Controller Mode Controller Mode 6-2. Applying Password - Setup Mode 6. PASSWORD At the Password Setup screen, press the 2 button. This menu is for setting the password to enter when changing controller setup values PASSWORD SETUP 1:PASSWORD SETUP upon power-on. 2:MENU ON 3:POWER ON Press Numeric Key 6-1.

  • Page 20: Priority

    Controller Mode Controller Mode 7. PRIORITY 8. DEFAULT This menu is for setting the connected sub-controller to use a PTZ camera or DVR within This menu is for resetting the changed controller setup values to the default values. the specified restrictions. This menu is available for master controller (ID: 1) only. At the [CONTROLLER SETUP 1 ] menu, press the CONTROLLER SETUP3...

  • Page 21: Matrix Mode (Smx-25632)

    MATRIX Mode MATRIX Mode MATRIX is another name for SAMSUNG SMX-25632. Select a number between 1 and 255, and then press AUTO SELECT SET the CAMERA button to select the corresponding CAM ID:1 MONITOR:12 [ --- ] 1. Selection of Camera and Monitor camera.

  • Page 22: Id Set

    MATRIX Mode MATRIX Mode 4-3. Setting the DISPLAY POSITION 4. ID SET From the initial screen, press the MONITOR button, This is a function to enter text on the corresponding and then press the MENU button to display the camera. <I/D SET>...

  • Page 23: Reference

    MATRIX Mode REFERENCE 5-2. Setting ON/OFF 1. Swing, Group Movement Speed From the initial screen, press the MONITOR button, For Swing setup, the speed setup value can be 240 /second for pan, and 180 /second and then press the MENU button to display the for tilt.

  • Page 24: Controller Specifications

    20 x 4 Character LCD PTZ Operation Joystick (3 axes Twist Zoom) Sub Keyboard Max. 16 things connection SPD-3300/3000/2300,SPD-2500/2200/1600, Speed Dome PELCO-D, PANASONIC (WV-CS854), SAMSUNG ELECTRONICS (SCC-643/641) Control SVR-1650/1640/950, SVR-1630/430 Receiver SRX-100B MATRIX SMX-25632 Control Quantity PTZ & DVR Max. 255 - Tour, Group, Swing, Preset etc.
