Summary of Contents for Westermo Wolverine DDW-002-B1
- Page 1 www.wester mo.com DDW-002-B1 EN 50155 Ethernet Broadband Bridge...
-
Page 2: Table Of Contents
Table of Contents 1. General Information ................ 3 1.1. Legal Information ..............3 1.2. About This Guide ..............3 2. Safety and Regulations ..............4 2.1. Warning Levels ..............4 2.2. Safety Information ..............5 2.3. Care Recommendations ............6 2.4. -
Page 3: General Information
Westermo reserves the right to revise this document or withdraw it at any time without prior notice. Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused. -
Page 4: Safety And Regulations
2. Safety and Regulations 2.1. Warning Levels Warning signs are provided to prevent personal injuries and/or damages to the product. The following levels are used: Level of warning Description Consequence Consequence personal injury material damage Indicates a potentially Possible death or major Major damage to the hazardous situation injury... -
Page 5: Safety Information
The power supply wiring must be sufficiently fused. It must be possible to disconnect manually from the power supply. Ensure compliance to national installation regulations. Replacing the internal fuse must only be performed by Westermo qualified personnel. WARNING - REDUCE THE RISK OF FIRE To reduce the risk of fire, use only telecommunication line cords with a cable diameter of AWG 26 or larger. -
Page 6: Care Recommendations
If the product is not working properly, contact the place of purchase, the nearest Westermo distributor office or Westermo technical support. 2.4. Product Disposal This symbol means that the product shall not be treated as unsorted municipal waste when disposing of it. -
Page 7: Compliance Information
2.5. Compliance Information 2.5.1. Agency Approvals and Standards Compliance Type Approval/Compliance • EN 50121-3-2/IEC 62236-3-2 Railway applications – Rolling stock – apparatus • EN 50121-4/IEC 62236-4, Railway signalling and telecommunications apparatus • EN/IEC 61000-6-1, Immunity residential environments • EN/IEC 61000-6-2, Immunity industrial environments •... -
Page 8: Simplified Declaration Of Conformity
2.5.3. Simplified Declaration of Conformity Hereby, Westermo declares that this product is in compliance with applicable EU directives and UK legislations. The full declaration of conformity and other detailed information is available at www.westermo.com/support/product-support. Figure 2. The European Conformity and the UK Conformity Assessment markings... -
Page 9: Product Description
EN 50155. For several characteristics, Westermo exceeds the requirements mandated by the standard. Furthermore, the design is based on Westermo’s long experience within the rolling stock market, which brings benefits such as vibration safe integrated connector threading, IP67 ingress protection with GORE-TEX®... -
Page 10: Hardware Overview
3.2. Hardware Overview 10/100 BASE/TX LINK LINK STATUS ACTIVITY LINK MASTER POWER M12 Torque 0,6±0,1Nm / 0,45±0,1 lbft Description Description Ethernet port Powerline connection Power connection Protective earth connection LED indicators Figure 3. Location of interface ports and LED indicators DDW-002-B1... -
Page 11: Led Indicators
3.3. LED Indicators Status Description Product has no power GREEN All OK, no alarm condition Product has no power GREEN Voltage present on DC1 Power failure on DC1 Product has no power GREEN Voltage present on DC2 Power failure on DC2 No link GREEN Link established... -
Page 12: Dimensions
3.4. Dimensions Dimensions are stated in mm and are regardless of model. 7,2 - 164 ±0,5 Figure 4. Dimensional drawing DDW-002-B1... -
Page 13: Installation
4. Installation 4.1. Wall Mounting There are four 6 mm bore holes intended for mounting the unit. The unit can be mounted vertical or horizontal. Use four M5 screws with 12 mm washer on a flat and stable surface. 10/100 BASE/TX LINK LINK STATUS ACTIVITY... -
Page 14: Connection Of Cables
The power supply wiring must be sufficiently fused. It must be possible to disconnect manually from the power supply. Ensure compliance to national installation regulations. Replacing the internal fuse must only be performed by Westermo qualified personnel. NOTE - UNUSED CONNECTORS... -
Page 15: Replacement Of Product
4.5. Replacement of Product Disconnect all cables and unscrew the product from the wall. MTTR (Mean Time To Repair), i.e. time for replacement of product is < 10 minutes. 4.6. EN 45545-2 Mounting Notes Two product can be mounted together and as a single interior non-listed group in the sense of EN 45545-2 definitions. -
Page 16: Configuration
4.8. Configuration All necessary configurations are preconfigured from factory and no other changes in the settings can be done. DDW-002-B1... -
Page 17: Specifications
Up to 150 m with CAT5e cable or better Isolation 1500 VAC rms to all other ports Connector 4-pin, female, M12, D-coded, auto MDI/MDI-X, recommended Westermo cables: 3146-1100 M12-M12 - 1 m 3146-1101 M12-M12 - 5 m 3146-1103 RJ45-M12 - 1 m... - Page 18 X2 powerline interface Data rate Up to 70 Mbit/s (depending on cable characteristics and temperature) Connector 4-pin, M12, B-coded Transmission range Up to 300 m (depending on cable characteristics and temperature) Electrical specification Supports communication over wires powered from 0 to 143 VDC DDW-002-B1...
-
Page 19: Type Tests And Environmental Conditions
5.2. Type Tests and Environmental Conditions Environmental Basic Description Test levels phenomena standard EN 61000-4-2 Enclosure Contact: ±6 kV Air: ±8 kV Fast transients EN 61000-4-4 Power port ± 2 kV Signal ports Earth port L-E: ± 2 kV, 42 Ω, 0.5 µF, 1.2/50 µs Surge EN 61000-4-5 Power port... - Page 20 Environmental Basic Description Test levels phenomena standard Temperatures EN 60068-2-1 Operational -40 to +70°C (-40 to +158°F) EN 60068-2-2 Storage and -50 to +85°C (-58 to +185°F) transport Humidity EN 60068-2-30 Operational 5-95% relative humidity Storage and transport Altitude Operational 2000 m/70 kPa Service life Operational...
-
Page 21: Revision Notes
5.1 Interface Specifications; Power port updated Rev. G 2021-05 Westermo logo updated, illustrations updated from brown to blue, new information structure throughout the manual, 1.2 About This Guide - new chapter, 2 Safety and Regulations - entire chapter updated. DDW-002-B1... - Page 22 Westermo • Metallverksgatan 6, SE-721 30 Västerås, Sweden Tel +46 16 42 80 00 Fax +46 16 42 80 01 E-mail: info@westermo.com www.westermo.com 6641-2280 REV. H 2021 10 Westermo Network Technologies AB, Sweden...
