www.wester mo.com
Viper-002-PL Series
EN 50155 Ethernet Powerline Bridge

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Viper-002-PL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Westermo Viper-002-PL Series

  • Page 1 Viper-002-PL Series EN 50155 Ethernet Powerline Bridge...
  • Page 2: Table Of Contents

    4.6. EN 45545-2 Mounting Notes ..........17 4.7. Getting Started ..............17 4.8. Configuration ..............18 5. Specifications ................19 5.1. Interface Specifications ............19 5.2. Type Tests and Environmental Conditions ......... 21 6. Revision Notes ................23 Viper-002-PL Series...
  • Page 3: General Information

    Westermo reserves the right to revise this document or withdraw it at any time without prior notice. Under no circumstances shall Westermo be responsible for any loss of data or income or any special, incidental, and consequential or indirect damages howsoever caused.
  • Page 4: Safety And Regulations

    No personal injury Minor damage to the order to avoid misuse of product the product, confusion or misunderstanding NOTICE Used for highlighting general, No personal injury Minor damage to the but important information product NOTE Table 1. Warning levels Viper-002-PL Series...
  • Page 5: Safety Information

    The power supply wiring must be sufficiently fused. It must be possible to disconnect manually from the power supply. Ensure compliance to national installation regulations. Replacing the internal fuse must only be performed by Westermo qualified personnel. REDUCE THE RISK OF FIRE To reduce the risk of fire, use only telecommunication line cords with a cable diameter of AWG 26 or larger.
  • Page 6: Care Recommendations

    If the product is not working properly, contact the place of purchase, the nearest Westermo distributor office or Westermo technical support. 2.4. Product Disposal This symbol means that the product shall not be treated as unsorted municipal waste when disposing of it.
  • Page 7: Compliance Information

    Energy source classifications are according to following: Electrical energy source Power port PL port Ethernet port ES1, TNV-1 Power source Power port PL port Thermal energy source Enclosure Mechanical energy source Enclosure Radiation energy source Table 2. EN/IEC/UL 62368-1 notice Viper-002-PL Series...
  • Page 8: Fcc Part 15.105 Class A Notice

    2.5.4. Simplified Declaration of Conformity Hereby, Westermo declares that this product is in compliance with applicable EU directives and UK legislations. The full declaration of conformity and other detailed information is available at www.westermo.com/support/product-support.
  • Page 9: Product Description

    The fact that no configuration is needed further contributes to the ease of use. The Viper-002-PL series has been thoroughly tested by certified labs to ensure its compliance with the standard for electronic equipment used on rolling stock, the EN 50155.
  • Page 10 Figure 3. Explanatory overview Viper-002-PL Series...
  • Page 11: Hardware Overview

    Description Description Ethernet port Powerline connection Power connection Protective earth connection LED indicators Figure 4. Location of interface ports and LED indicators 3.4. Connector Pinout Pin no. Signal Illustration +DC1 +DC2 -COM -COM Table 3. Power connector, A-coded Viper-002-PL Series...
  • Page 12 Pin no. Signal Illustration Auto MDI/MDI-X is used. The table shows signals in MDI mode. Table 4. Ethernet connector, D-coded Pin no. Signal Illustration PLC1 PLC2 PLC1 and PLC2 are polarity free Table 5. Powerline connector, B-coded Viper-002-PL Series...
  • Page 13: Led Indicators

    Product has no power GREEN Voltage present on DC2 Power failure on DC2 No link GREEN Link established GREEN FLASH Data traffic indication X2:1 No PLC link established PLC link established X2:2 GREEN X2:3 Table 6. LED indicators Viper-002-PL Series...
  • Page 14: Dimensions

    3.6. Dimensions Dimensions are stated in mm and are regardless of model. 7,2 - 10/100 BASE-TX LINK X2:1 X2:2 X2:3 24-110 V M12 Torque 0,6±0,1Nm / 0.45±0.1 Ibft 164 ±0,5 Figure 5. Dimensional drawing Viper-002-PL Series...
  • Page 15: Installation

    24-110 V M12 Torque 0,6±0,1Nm / 0,45±0,1 lbft Figure 6. Wall mounting 4.2. Protective Earth Connection For correct function, the earth connection needs to be properly connected to a designated PE rail. Torx: T25 and torque: 3.2 Nm. Viper-002-PL Series...
  • Page 16: Connection Of Cables

    The power supply wiring must be sufficiently fused. It must be possible to disconnect manually from the power supply. Ensure compliance to national installation regulations. Replacing the internal fuse must only be performed by Westermo qualified personnel. NOTE - UNUSED CONNECTORS...
  • Page 17: Replacement Of Product

    If the PLC link is not established or the established data rate is not suffcient for the application, the distance might be too long between the products. The product is an unmanaged unit. If performance is low or no connection established, check cabling between the product. Viper-002-PL Series...
  • Page 18: Configuration

    4.8. Configuration All necessary configurations are preconfigured from factory and no other changes in the settings can be done. Viper-002-PL Series...
  • Page 19: Specifications

    Up to 150 m with CAT5e cable or better Isolation 1500 VAC rms to all other ports Connector 4-pin, female, M12, D-coded, auto MDI/MDI-X, recommended Westermo cables: 3146-1100 M12-M12 - 1 m 3146-1101 M12-M12 - 5 m 3146-1103 RJ45-M12 - 1 m...
  • Page 20 4-pin, M12, B-coded Transmission range Up to 400 m with full rate, up to 1000 m with reduced data rate (depending on cable characteristics and temperature) Electrical specification Supports communication over wires powered from 0 to 143 VDC Viper-002-PL Series...
  • Page 21: Type Tests And Environmental Conditions

    Ethernet ports Dielectric strength EN 50155 Power port to all 1.5 kVAC rms, 50 Hz, 1 min other ports Fast Ethernet ports to all other ports Link to all other ports Table 7. EMC and electrical conditions Viper-002-PL Series...
  • Page 22 11.44 m/s2 rms 5-150Hz (random) Shock Operational 10 g, 30 ms, 60068-2-27 20 g, 11 ms Enclosure EN 62368-1 Zinc Fire enclosure Weight 1,2kg Degree of protection EN 60529 Enclosure IP67 Cooling Convection Table 8. Environmental and mechanical conditions Viper-002-PL Series...
  • Page 23: Revision Notes

    6. Revision Notes Revision Date Change description Rev. A 2023-11 First version Viper-002-PL Series...
  • Page 24 Westermo • Metallverksgatan 6, SE-721 30 Västerås, Sweden Tel +46 16 42 80 00 Fax +46 16 42 80 01 E-mail: info@westermo.com www.westermo.com 6635-2201 REV. A 2023 11 @ Westermo Network Technologies AB, Sweden...
