Summary of Contents for SunSynk SUN-8.0

  • Page 1 Sunsynk Hybrid Inverters with lithium-ion batteries...
  • Page 2 Sunsynk inverter(s) and lithium-ion batteries is the ideal package for self-consumption, off-grid and back-up solar PV systems. The Sunsynk hybrid inverter is a bi-directional energy storage unit that consists of the 5kW and 8kW single phase inverter models. On the other hand, the Pylontech 48V batteries and FreedomWon range models are the recommended batteries for use with the Sunsynk series inverters.
  • Page 3 2.1 Basic This tab allows the user to enter details such as the time, display name etc. Please ensure that the correct time settings are entered as this could influence the functionality of the inverter especially if timed settings will be use. 2.2 Battery *Note: Ensure that the Grid and PV power sources are turned off before starting the inverter and until the battery communication and configuration is successful.
  • Page 4 Sunsynk Freedom Won setup Before commencing with the installation please ensure Figure 5: Sunsynk and Freedom Won BMS cable that the BMS cable is as per definition in Figure 5. After pinouts the communication cable is connected, please ensure that the Li-BMS page under settings is as in Figure 2.
  • Page 5 Protocol is set to 0. The “Batt capacity”, “Charge Amps” and “Discharge Amps” will be dependent on the type of battery you have as well as the bank size. Finally, ensure that “BMS_Err_Stop” is ticked Sunsynk US3000/US2000B setup Before commencing with the installation please...
  • Page 6 Figure 8: System Mode page setup The SegenSolar portal has a System Designer tool which allows you to create your systems. Please speak to your account manager if you require training on how to use the System Design tool. The design tool will allow you to create a quote quickly and easily with all the necessary components...
  • Page 7 End page JOHANNESBURG CAPE TOWN 245 Masjien Street, Strijdompark, 1 Gulfstream Avenue Randburg, Gauteng, 2194 Matroosfontein, Cape Town Email: info@segensolar.co.za Western Cape, 7490 Johannesburg: +27 (0) 11 085 2600 / Email: info@segensolar.co.za 087 802 0663 Cape Town: +27 (0) 21 001 0589...
