PROBLEM
Unit will not start.
Battery packwill not charge.
PROBLEM
Automatic line feed does not feed
more line.
Overfeeding
Line unravels when cap or spool
is removed.

SERVICE INFORMATION

BLACK+DECKER offers a full network of company-owned and authorized service locations. All BLACK+DECKER
Service Centers are staffed with trained personnel to provide customers with efficient and reliable power tool service.
For more information about our authorized service centers and if you need technical advice, repair, or genuine factory
replacement parts, contact the BLACK+DECKER location nearest you, or visit us at www.BlackandDecker-la.com

TROUBLESHOOTING

POSSIBLE CAUSE
Battery pack not installed properly.
Battery pack not charged.
Attachment is not secured.
Battery pack not inserted into charger.
Charger not plugged in.
Surrounding air temperature too hot
or too cold.
POSSIBLE SOLUTION
More line is fed when the line shortens to approximately 3" (76,2 mm). To
determine if the line is not feeding, let line wear past this point.
Keep the tabs depressed and remove the spool from the spool housing in the trimmer head.
Ensure that the line is not crisscrossed on the spool as detailed in Fig. O. If it is, unwind the
cutting line, then wind it back on the spool neatly so that the lines do not cross.
Inspect tracks at the bottom of spool for damage. If damaged, replace spool.
Pull the cutting line until it protrudes approximately 4-13/16" (122 mm) from the spool. If
insufficient cutting lin is left on the spool, install a new spool of cutting line.
Align the tabs on the spool cap with the cut outs in the housing.
Push the spool cap onto the housing until it snaps securely into place.
If the cutting line protrudes beyond the trimming blade, cut it off so that it just
reaches the blade. If the automatic line feed still does not work or the spool is
jammed, try the following suggestions:
f Carefully clean the spool and housing.
f Make sure you are using correct line size and diameter (0,065" (1,65 mm)) -
smaller and larger line sizes will affect the functionality of the auto feed system.
f Remove the spool and check if the lever in the spool housing can move freely.
f Remove the spool and unwind the cutting line, then wind it on neatly again.
Replace the spool into the housing.
Ensure you are cutting with the tip of the line (7" (177,8 mm) from the spool).
Use the edge guide if needed to ensure proper space is maintained.
Ensure you are not exceeding a 10° angle as shown in Fig. G1.
Make sure to park the lines in holding slots (Fig. N) before removing.
ENGLISH • 41
POSSIBLE SOLUTION
Check battery pack installation.
Check battery pack charging requirements.
Make certain the attachment is fully pushed
into the Power Unit.
Insert battery pack into charger until green
LED appears.
Plug charger into aworking outlet. Refer to
"Important Charging Notes" formore details.
Move charger and battery pack to
a surrounding air temperature of above 40°F
4,5°C) or below 105°F (+40,5°C).
