Summary of Contents for TRENDnet TPE-P521ES

  • Page 1 Cover Page TRENDnet User’s Guide...
  • Page 2: Table Of Contents

    SNMP ........................... 13 Configure Storm Control ..................29 Global Settings ....................13 Set Ingress Rate Limiting..................30 Community Table Settings ................. 14 Set Egress Rate Limiting ..................31 Host Settings ...................... 15 VLAN ..........................32 © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 3 Configure PoE settings ..................46 Tools ..................... 47 Firmware Upgrade ....................... 47 Upgrade your switch firmware ................47 Configuration ....................... 48 Backup and Restore your switches configuration setting........48 Diagnostics ........................49 Cable Diagnostics Test ..................49 © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 4: Product Overview

    In addition to your switch, the package includes:  Quick Installation Guide If any package contents are missing or damaged, please contact the retail store, online retailer, or reseller/distributor from which the product was purchased. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 5: Product Hardware Features

    Gigabit Ethernet Ports (3-4) – Connect non-PoE network devices.  Gigabit Ethernet PoE+ in Ports (5) – Must be connected to a PoE or PoE+ power source in order to power this switch. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 6: Led Indicators

    Rack Mounting.  When installing the Switch on a level surface, attach the rubber feet to the bottom of each device. The rubber feet cushion the hub and protect the hub case from scratching. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 7: Basic Ip Configuration

    192.168.10.x (e.g. 192.168.10.25) and a subnet mask of 255.255.255.0. 4. Open your web browser, and type the IP address of the switch in the address bar, and then press Enter. The default IP address is 192.168.10.200. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 8 1. From the menu on the left: click on Save, then click the blue button Save Settings to Flash. 2. Click Continue to return to the Web Configuration of your switch. 8. When confirmation message appears click OK. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 9: Connect Additional Devices To Your Switch

    Note: If you encounter issues connecting to your network, there may be a problem with your computer or device network settings. Please ensure that your computer or device network settings (also called TCP/IP settings) are configured properly within the network subnet your switch is connected. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 10: Accessing Switch Management Interfaces

     System Location - Displays the identifying system location of your switch. This information can be modified under the System section.  System Contact – Displays the identifying system contact or system administrator of your switch. This information can be modified under the System section. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 11  Default Gateway – Displays the current gateway address assigned to your switch. Automatic Network Features  IPv4 DHCP Client Mode: Displays if your switch IPv4 address setting is set to DHCP client. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 12: System

    30 characters.  System Contact - Specifies the name of the network administrator responsible for managing the switch. This contact name is optional and may contain up to 30 characters. 4. Click Apply. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 13: Ipv4 Settings

     System IP Mode: Click the drop-down list and select Static to manually specify your IP address settings or DHCP to allow your switch to obtain IP address settings automatically from a DHCP server on your network. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 14: Administration

    NOTE: The configured settings are only applied to the switch’s temporary memory and will be lost upon the next power-cycle. Please follow these next steps to save the configurations to the switch’s NV-RAM to ensure the settings will remain throughout power-cycles and reboots: © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 15: Timeout

    NV-RAM to ensure the settings will remain throughout power-cycles and reboots: 1. From the menu on the left: click on Save, then click the blue button Save Settings to Flash. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 16: Snmp

    NOTE: The configured settings are only applied to the switch’s temporary memory and will be lost upon the next power-cycle. Please follow these next steps to save the configurations to the switch’s NV-RAM to ensure the settings will remain throughout power-cycles and reboots: © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 17: Community Table Settings

    SNMP User and Group Name on the SNMP User/Group page and then define a Community Name on the SNMP Community Table page. 1. Log into your switch management page (see “Access your switch management page” on page 7). © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 18: Host Settings

    3. Review the settings. 2. Click Continue to return to the Web Configuration of your switch.  Enter the Host IPv4 Address for the management device that is to receive the SNMP traps. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 19: Statistics

    RxErr: Receive Error, number of frames that were failed to be received by the switch through the specified port number.  Clear: Clicking Apply will clear the Statistic Information of that row (port number). © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 20: Ieee 802.3Az Eee

    NV-RAM to ensure the settings will remain throughout power-cycles and reboots: 1. From the menu on the left: click on Save, then click the blue button Save Settings to Flash. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 21: Network

    You can also disable an disable Auto-Negotiation on the port and set the port’s speed and unused port to secure it from unauthorized connections. The possible values duplex mode manually. are: © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 22 Disabled -This parameter indicates the switch is not permitted to accept jumbo frames. Note: When QoS is enabled, the Jumbo frame parameter cannot be enabled. 2. Click Continue to return to the Web Configuration of your switch. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 23: Spanning Tree

    STP Traps: You may set conditional triggers for automatically exporting logs upon: STP New Root Trap – Triggers when a new STP root is created. STP Topology Change Trap – Triggers when any change in the topology of the STP is detected. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 24: Configure Spanning Tree Protocol Port Settings

    Please follow these next steps to save the configurations to the switch’s NV-RAM to ensure the settings will remain throughout 2. Click on Network, click on Spanning Tree, and click on RSTP Port Settings. power-cycles and reboots: © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 25: Trunk

    LACP Global Settings: To enable Trunking/Link Aggregation, select Enable. Otherwise, trunk settings with remain in its default state (Disabled).  For each Trunk ID/Group, check the port numbers to add for each trunk group. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 26: Mirroring

    To copy data transmitted on specific port, select Egress as the Frame Type and check the port number(s) under the section or you could click All to copy data received on all ports. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 27: Loopback Detection

    Recover Time – Defines the time period when connectivity will be restored to a port where a loop was previously detected and blocked. Click Apply to save changes. 2. Click Continue to return to the Web Configuration of your switch. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 28 NOTE: The configured settings are only applied to the switch’s temporary memory and will be lost upon the next power-cycle. Please follow these next steps to save the configurations to the switch’s NV-RAM to ensure the settings will remain throughout power-cycles and reboots: © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 29: Static Unicast

    Port Member – Select the port where the MAC address will reside. Settings to Flash. Click Apply to add the Static Unicast entry to the list. 2. Click Continue to return to the Web Configuration of your switch. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 30: Static Multicast

    Note: You can click All to select all ports. Click Apply to add the Static Multicast Group entry to the list. 2. Click Continue to return to the Web Configuration of your switch. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 31: Igmp Snooping

    NV-RAM to ensure the settings will remain throughout power-cycles and reboots: 1. From the menu on the left: click on Save, then click the blue button Save Settings to Flash. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 32: Bandwidth Control

    NOTE: The configured settings are only applied to the switch’s temporary memory and will be lost upon the next power-cycle. Please follow these next steps to save the configurations to the switch’s NV-RAM to ensure the settings will remain throughout power-cycles and reboots: © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 33: Set Ingress Rate Limiting

    2. Click on Network, click on Bandwidth Control, and click on Ingress Rate Limiting. 3. Review the settings for each port. Click Apply to save the settings.  Bandwidth – Select the bandwidth limit in bits per second from the dropdown menu. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 34: Set Egress Rate Limiting

    NOTE: The configured settings are only applied to the switch’s temporary memory and will be lost upon the next power-cycle. Please follow these next steps to save the configurations to the switch’s NV-RAM to ensure the settings will remain throughout power-cycles and reboots: © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 35: Vlan

    VLAN ports to add to the new VLAN (Tagged or Untagged) and assign ports that are not members (Forbidden) of the new VLAN. Click Apply to save the new VLAN to the table. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 36: Configure Vlan Port Settings

    NV-RAM to ensure the settings will remain throughout power-cycles and reboots: 1. From the menu on the left: click on Save, then click the blue button Save Settings to Flash. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 37: Configure The Vlan Forwarding Table

    802.1Q VLAN mode when possible. Please note the following when switching between forwarding table modes:  FDB (Forwarding Database) will be cleared.  Static Unicast Address entries will be cleared. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 38: View The Switch Vlan Dynamic Forwarding Table

    PVID must match its corresponding secondary VLAN ID. Ports within a secondary VLAN cannot be members of other VLANs. All VLANs that make up the private VLAN must belong to the same Spanning Tree Group. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 39 NOTE: The configured settings are only applied to the switch’s temporary memory and will be lost upon the next power-cycle. Please follow these next steps to save the configurations to the switch’s NV-RAM to ensure the settings will remain throughout power-cycles and reboots: © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 40: Voice Vlan

    MAC address of at least one of your IP phones. An “OUI Mask” is automatically packets entering the port are switched within the voice VLAN as the voice data passes generated and applied by the Web Management Utility software to yield the through the switch. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 41: Create A Voice Vlan

    VLAN ID - This parameter is the tagged VLAN ID that has been configured in “Tagged VLAN Configuration”. It is a pull-down menu showing the tagged VLAN IDs that have been defined. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 42: Configure Voice Vlan Oui Settings

    Note: If you find more than one OUI among the IP phones you are installing, enter one MAC address that represents each individual OUI. You can enter a total of 5 OUIs. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 43 TPE-P521ES TRENDnet User’s Guide 2. Click Continue to return to the Web Configuration of your switch. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 44: Qos

    1. Log into your switch management page (see “Access your switch management page” on page 7). 2. Click on QoS and click on CoS. 3. To enable the function, select Enabled in QoS Status, and then click Apply. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 45: Port Priority

    3. For each port whose priority you want to change, select a priority in the User Priority 2. Click Continue to return to the Web Configuration of your switch. column. Click Apply to save the settings. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 46: Dscp

    NOTE: The configured settings are only applied to the switch’s temporary memory and will be lost upon the next power-cycle. Please follow these next steps to save the configurations to the switch’s NV-RAM to ensure the settings will remain throughout power-cycles and reboots: © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 47: Scheduling Algorithm

    NV-RAM to ensure the settings will remain throughout power-cycles and reboots: 1. From the menu on the left: click on Save, then click the blue button Save Settings to Flash. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 48: Poe

    Maximum Power Class Output Power Ranges of the PDs from a Switch Port 15.4W 0.44W to 12.95W 4.0W 0.44W to 3.84W 7.0W 3.84W to 6.49W 15.4W 6.49W to 12.95W 25.5W 12.95W to 25.5W © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 49: Configure Poe Settings

    Power (W) - Indicates the Power in watts that the port is supplying power to the PD.  Voltage (V) - Indicates the Voltage in volts as measured at the port when the port is supplying power to the PD. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 50: Tools

    TRENDnet may periodically release firmware upgrades that may add features or fix on page 7). problems associated with your TRENDnet switch model and version. To check if there is a firmware upgrade available for your device, please check your TRENDnet model and 2.
  • Page 51: Configuration

    4. A separate file navigation window should open. 5. Select the switch configuration file to restore and click Restore. (Default Filename: config.bin). If prompted, click Yes or OK. 6. Wait for the switch to restore settings. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 52: Diagnostics

    The results will be displayed in the Cable Diagnostic Table below.  Test Results: Displays the diagnostic results for each pair in the cable. One of the following cable status parameters is displayed: OK: There is no problem detected with the cable. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 53: Reboot

    3. Click the Reboot Type drop-down list and select Normal and click Apply to initiate a reboot. Wait for the switch complete the rebooting process. The switch factory default settings are below. Administrator User Name admin Administrator Password admin Switch IP Address 192.168.10.200 Switch Subnet Mask 255.255.255.0 © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 54: Using The Edge Smart Switch Management Utility

    Using the Edge Smart Switch Management Utility The Web Smart Management Utility allows you to do the following:  You can easily discover all TRENDnet web smart switches on your network using the discover feature.  You can modify the IP address settings, change the admin password, and upgrade firmware for multiple switches.
  • Page 55: Using The Utility

    6. In the Completion window, click Finish. You can also launch the utility from the Start Menu programs. Start > Programs (or All Programs) > TRENDnet Management Utility > TRENDnet Management Utility.exe © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 56: Discovery List

    Add Item: To add a device to the Monitor List manually, enter the IP Address of  Group Interval: the device that you want to monitor.  Delete Item: To delete the device in the Monitor List. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 57: Device Setting

    “Set” to process the data change immediately. The default password of TRENDnet Web Smart Switches is “admin”. Access Web: Double click the device in the Monitor List or select a device in the Monitor List and press this “Web Access”...
  • Page 58: Main Menu Options

    Choose 15 secs, 30 secs, 1 min, 2 min and 5 min to select the time of monitoring.  Group Interval: 120~1225 In the “Help TAB”, there is About function, it will show out the version of the Web Management Utility. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 59: Technical Specifications

    Switch fabric: 10Gbps   Block unknown multicast source RAM buffer: 512KB   Up to 32 multicast groups MAC Address Table: 2K entries  Jumbo Frames: 9KB  Forwarding rate: 7.44Mpps (64-byte packet size) © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 60 8W PoE Budget with IEEE 802.3af (15.4W) input power  PoE Mode A: Pins 1,2 for power and pins 3,6 for power  PD auto classification  Over current/short circuit protection Fan / Acoustics  Fanless design MTBF  730,455 hours © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 61: Quick Installation Guidetroubleshooting

    Then click Use the following IP address, and make sure to assign your network adapter an IP address in the subnet of 192.168.10.x. Click OK Note: If you are experiencing difficulties, please contact your computer or operating system manufacturer for assistance. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 62: Appendix

    From the Location drop-down list, select Automatic. 2. In the Network Preference window, next to "Show:", select Network Status. You'll see d. Select and view your Ethernet connection. your network status and your IP address settings displayed. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 63 2. Select Ethernet from the list on the left. Example: ping –c 4 192.168.10.100 3. Click the Advanced button. 3. On the Ethernet tab, the Ethernet ID is your MAC Address. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 64 Country Code selection feature to be disabled for products marketed to the US/CANADA CE Mark Warning This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 65 TPE-P521ES TRENDnet User’s Guide reikalavimus ir kitas 2014/30/EU ir 2004/108/EB Direktyvos TRENDnet tímto prohlašuje, že tento TPE-P521ES je ve shodě se Česky [Czech] nuostatas. základními požadavky a dalšími příslušnými ustanoveními směrnice 2014/30/EU a 2004/108/ES. Hierbij verklaart TRENDnet dat het toestel TPE-P521ES in Nederlands overeenstemming is met de essentiële eisen en de andere...
  • Page 66 An RMA number is required in order to initiate warranty service support the event that the RMA unit needs to be replaced, TRENDnet may replace it with a for all TRENDnet products. Products that are sent to TRENDnet for RMA service must refurbished product of the same or comparable model.
  • Page 67 OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND evidence of the original purchaser's date of purchase. Replacement products may be OF THE PURCHASE PRICE PAID, AT TRENDNET'S OPTION. THIS DISCLAIMER OF LIABILITY refurbished or contain refurbished materials. If TRENDnet, by its sole determination, is...
