Quick Installation Guide
TPE-S160
1.01

Advertisement

loading
Need help?

Need help?

Do you have a question about the TPE-S160 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TRENDnet TPE-S160

  • Page 1 Quick Installation Guide TPE-S160 1.01...
  • Page 2: Table Of Contents

    Table of Contents English 1. Before You Start LEDs 3. Hardware Installation Technical Specifications Troubleshooting Version 03.23.2010...
  • Page 3: English

    1. Before You Start Package Contents Ÿ TPE-S160 Ÿ Multi-Language Quick Installation Guide Ÿ Power cord (1.8m / 6ft) Ÿ Rackmount Kit System Requirements Computer with Network adapter installed Ÿ RJ-45 Network Cable Ÿ The surface must support at least 3.8 kg (8.4 lb) for the Switch. Ÿ...
  • Page 4: Leds

    2. LEDs Power PoE (Power over Ethernet) Link/ACT Device Status LED Color Sequence Definition Device powered On Amber Solid Power Device powered Off Solid Amber PoE device is connected (Power over Ethernet) No PoE device is connected. Green Solid Link/ACT 10/20Mbps (Half/Full Duplex) or 100/200Mbps (Half/Full Duplex) Duplex Connected (per port)
  • Page 5: Hardware Installation

    3. Hardware Installation 1. Connect the Power Cord to the TPE-S160 and then to a power outlet. 2. Move the Power switch to the on position. 3. Connect a RJ-45 network cable from the computer to an available Ethernet port on the TPE-S160.
  • Page 6 4. Connect a RJ-45 cable from a PoE port (1~16) on the TPE-S160 to the LAN port of the PoE device (e.g. TEW-638PAP) 5. Verify that the following TPE-S160 LED are on: Power, PoE and Link/ACT.
  • Page 7 Using a non-PoE device with the TPE-S160 and the TPE-112GS (PoE Splitter) Note: Take note of the power requirements for your non-PoE device. The TPE-112GS only supports non-PoE devices with an output power of 5V, 7.5V, 9V or 12V DC. 1.
  • Page 8 Rack Mount The Switch can be mounted in an EIA standard-size, 19-inch rack, which can be placed in a wiring closet with other equipment. 1. Attach the mounting brackets to both sides of the chassis and secure them with the provided screws.
  • Page 9: Technical Specifications

    Technical Specifications Hardware Ÿ IEEE 802.3 10Base-T Ÿ IEEE802.3u 100Base-TX Standard Ÿ IEEE 802.3af Power over Ethernet Ÿ IEEE 802.3x Flow Control Ports 16 x 10/100Mbps Auto-MDIX PoE ports Power Switch On/Off power switch Ÿ Ethernet: 10/20Mbps (half/full duplex) Data Transfer Rates Ÿ...
  • Page 10: Troubleshooting

    5. Where is the uplink port located on the Switch? Since all the ports on the Switch are Auto-MDIX, any of the ports can be used as an uplink port. If you still encounter problems or have any questions regarding the TPE-S160 please contact Trendnet's Technical Support Department.
  • Page 11 RMA number is required in order to initiate warranty service support for all TRENDnet products. Products that are sent to TRENDnet for RMA service must have the RMA number marked on the outside of return packages and sent to TRENDnet prepaid, insured and packaged appropriately for safe shipment.
  • Page 12 Download section and look for the desired TRENDnet product to access to the GPL Code or LGPL Code. These codes are distributed WITHOUT WARRANTY and are subject to the copyrights of the developers. TRENDnet does not provide technical support for these codes. Please go to http://www.gnu.org/licenses/gpl.txt...
  • Page 17 Copyright ©2011. All Rights Reserved. TRENDnet.
