Page 1: Table Of Contents
SIPmon SIPProt Desktop & Mobile UADs Appliances From Bicom Systems Wiki Contents 1 Introduction - How to use ReadyNet AC1200MS with PBXware 1.1 Requirements 2 Installation 2.1 Power Adapter 2.2 IP Address 2.3 Factory Settings 3 Registering Device 3.1 Manual Configuration 3.2 Auto Provisioning... -
Page 2: Requirements
This "How to" is written as a general guide on how to use your ReadyNet AC1200MS with PBXware 5.3.1.0. It covers the most common tasks required in order to have your ReadyNet AC1200MS working efficiently. Requirements 1. Identify ReadyNet device To start and successfully complete registration of your ReadyNet device you need to know which device model you will setup. -
Page 3: Power Adapter
This step is not required for out-of-the-box devices, however, if the device has been already used then it is a must. For ReadyNet AC1200MS press the reset button at the front of your router for 10 seconds, this will wipe out any changes made to your router. - Page 4 2. UAD settings Navigate to Settings:UAD. Make sure ReadyNet AC1200MS UAD is enabled. To check the UAD status click on the edit icon corresponding to your ReadyNet AC1200MS UAD phone. Make sure Status is set to Active, Auto provisioning is set to No, and DHCP is set to Yes.
- Page 5 "1234" or "1003" etc. An auto-generated PIN will allow access to voicemail and online self-care. Registering Phone This chapter describes how to register ReadyNet AC1200MS device using Hostname or IP Address. Hostname or IP Address 1. Login to device web administration interface Open a new browser window and enter your phone IP address in order to access the device web administration interface login screen.
-
Page 6: Auto Provisioning
Click on FXS1 tab at the top navigation menu. Enter the following details into the respective fields. REQUIRED FIELDS: Proxy Server (Proxy and Registration section) Enter the Hostname or IP Address of the PBXware. - Example for Hostname: voip.bicomsystems.com - Example for IP Address: 192.168.1.10 Display name (Subscriber Information section) PBXware extension name. - Page 7 2. UAD settings Navigate to Settings:UAD. Make sure ReadyNet AC1200MS UAD is enabled. To check the UAD status click on the edit icon corresponding to your ReadyNet AC1200MS phone. Make sure Status is set to Active, Auto provisioning is set to Yes, and DHCP is set to Yes.
- Page 8 TFTP 1. Login to device web administration interface If there is no DHCP in your network, you can still auto provision your ReadyNet AC1200MS device. Please refer to your ReadyNet AC1200MS phone device User Guide for instruction about setting static IP address. After you configure your ReadyNet device to use a static IP address, continue with the following steps.
- Page 9 Click on Administration tab at the top navigation menu. Click on Provision tab. In the Profile Rule field enter tftp:// followed by Hostname or IP Address, followed then by /$MA.conf. - Example for Hostname: tftp://voip.bicomsystems.com/$MA.conf - Example for IP Address: tftp://192.168.1.10/$MA.conf Make sure that Option 66 is DISABLED.
