ReadyNet WRT-500 Quick Installation Manual

Step 2: Wireless Security Setup
Your router is pre-configured with wireless security
from the factory. The default wireless pass phrase
is printed on the sticker on the bottom of the router.
If you would like to change the factory-set pass
phrase, click 'Wireless' then 'Wireless Security'.
If, for example, you want to use WPA-PSKWPA2-PSK
as the Security mode, TKIPAES as the WPA algorithm,
and abcxyz123 as the pass phrase, your setting would
Figure 3
be like Figure 3
IMPORTANT: Click the 'Reboot' button at the bottom of the page to save your settings.
D. Setting Up Your Wireless Devices
Your wireless devices (desktop, laptop, iPad, smart-phone,
WRT500
etc.) must be configured to work with your wireless router.
Each of these devices must have an internal or external
Wireless N Router
wireless adapter and applicable drivers. User guides for
each of these devices should have instructions for wireless
set up. You will need the SSID and password you assigned
to this wireless router during router set up. For each Your WRT500 has been pre-configured with an SSID
wireless device, access the setup menu, choose the
(wireless network name) and security pass phrase.
appropriate SSID from the list of wireless networks, enter
See the sticker on the bottom of your router for this
your password, and test the wireless connection.
information. If you wish to change these or other
settings, use the following instructions.

Quick Installation Guide
