Frigidaire FRT21GNH Factory Parts Catalog

R134a system series
Hide thumbs Also See for FRT21GNH:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT21NNHB1
FRT21NNH
FRT21NNHD1
FRT21NNH
FRT21NNHQ1
FRT21GNH
FRT21NNHW1
FRT21NNH
MARKET
North America
WIRING DIAGRAM - # 193832
OWNER'S GUIDE - # 218942600
SERVICE DATA SHEET - # 218755000
101 MASTERS BLVD.
ANDERSON, SC 29624
This catalog supercedes
Publication No. 5995323887
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
black
R134a System
almond
R134a System
bisque
R134a System
white
Publication No.
5995326302
990803
-EN/SERVICE/KB
REFRIGERATOR
VOLTS
115
115
115
115
REFRIGERATOR
Model No.
FRT21NNH
©1999 White Consolidated Industries, Inc.
All rights reserved

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21GNH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT21GNH

Summary of Contents for Frigidaire FRT21GNH

  • Page 1 PRODUCT NO. BASE MODEL NO. FRT21NNHB1 FRT21NNH FRT21NNHD1 FRT21NNH FRT21NNHQ1 FRT21GNH FRT21NNHW1 FRT21NNH MARKET North America WIRING DIAGRAM - # 193832 OWNER’S GUIDE - # 218942600 SERVICE DATA SHEET - # 218755000 101 MASTERS BLVD. ANDERSON, SC 29624 This catalog supercedes Publication No.
  • Page 2 Publication No. FRT21NNH 5995326302 DOOR 10/99...
  • Page 3 A = FRT21NNH (FRT21NNHB1) B = FRT21NNH (FRT21NNHD1) C = FRT21NNH (FRT21NNHQ1) D = FRT21NNH (FRT21NNHW1) POS. NO 37A* 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRT21NNH DOOR PART NO DESCRIPTION 215608923 A - - - Gasket-frzr door,black ,magnetic 215608913 - B C D Gasket-frzr door,white ,magnetic...
  • Page 4 Publication No. FRT21NNH 5995326302 CABINET 10/99...
  • Page 5 A = FRT21NNH (FRT21NNHB1) B = FRT21NNH (FRT21NNHD1) C = FRT21NNH (FRT21NNHQ1) D = FRT21NNH (FRT21NNHW1) POS. NO 13 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21NNH CABINET PART NO DESCRIPTION 5304402655 A B C D Cover-fan 5303307351 A B C D Knob-damper control 5303001028...
  • Page 6 Publication No. FRT21NNH 5995326302 CABINET 10/99...
  • Page 7 A = FRT21NNH (FRT21NNHB1) B = FRT21NNH (FRT21NNHD1) C = FRT21NNH (FRT21NNHQ1) D = FRT21NNH (FRT21NNHW1) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRT21NNH CABINET PART NO DESCRIPTION 5308016566 A B C D Screw,hex wshr hd ,8-15A x 0.625, low profile 5308000107 A B C D Bracket-connector...
  • Page 8 Publication No. FRT21NNH 5995326302 SHELVES 10/99...
  • Page 9 A = FRT21NNH (FRT21NNHB1) B = FRT21NNH (FRT21NNHD1) C = FRT21NNH (FRT21NNHQ1) D = FRT21NNH (FRT21NNHW1) POS. NO 14 # 19 # 21 # 23 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21NNH SHELVES PART NO DESCRIPTION 218651902 A - - - Mullion,black 218651901...
  • Page 10 Publication No. FRT21NNH 5995326302 SYSTEM P05C0101 10/99...
  • Page 11 A = FRT21NNH (FRT21NNHB1) B = FRT21NNH (FRT21NNHD1) C = FRT21NNH (FRT21NNHQ1) D = FRT21NNH (FRT21NNHW1) POS. NO 13 # 14 # 15 # 21 # 30 # # = Fast-moving Parts * = Non-Illustrated Parts FRT21NNH SYSTEM PART NO DESCRIPTION 218657100 A B C D...

  • Page 12: Wiring Schematic

    Publication No. FRT21NNH 5995326302 WIRING SCHEMATIC 10/99...

  • Page 13: Wiring Diagram

    FRT21NNH Publication No. 5995326302 WIRING DIAGRAM # = Fast-moving Parts 10/99 * = Non-Illustrated Parts...
