Frigidaire FRT21G3A Factory Parts Catalog
Frigidaire FRT21G3A Factory Parts Catalog

Frigidaire FRT21G3A Factory Parts Catalog

Top mount refrigerator r134a series
Hide thumbs Also See for FRT21G3A:

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FRT21G3AQ2
FRT21G3A
FRT21G3AW2
FRT21G3A
MARKET
North America
WIRING DIAGRAM - 240379007
OWNER'S GUIDE - 240400105
SERVICE DATA SHEET - 240379007
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995362091
011211
-EN/SERVICE/KHB
357
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21G3A
©2001 White Consolidated Industries, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21G3A and is the answer not in the manual?

Questions and answers

Summary of Contents for Frigidaire FRT21G3A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21G3AQ2 FRT21G3A R134a bisque FRT21G3AW2 FRT21G3A R134a white MARKET North America WIRING DIAGRAM - 240379007 OWNER’S GUIDE - 240400105 TOP MOUNT SERVICE DATA SHEET - 240379007 REFRIGERATOR Model No. FRT21G3A ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O.
