Frigidaire FRT21GNH Factory Parts Catalog
R134a series
Hide thumbs
Also See for FRT21GNH:
- Factory parts catalog (11 pages) ,
- Factory parts catalog (13 pages)
Advertisement
Quick Links
Download this manual
See also:
Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21GNHD0
FRT21GNH
FRT21GNHW0
FRT21GNH
MARKET
North America
WIRING DIAGRAM - # 193832
OWNER'S GUIDE - # 218921600
SERVICE DATA SHEET - # 218755000
101 MASTERS BLVD.
ANDERSON, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
almond
R134a
white
Publication No.
5995321006
990414
-EN/SERVICE/KB
357
REFRIGERATOR
VOLTS
115
115
REFRIGERATOR
Model No.
FRT21GNH
©1999 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21GNH
Summary of Contents for Frigidaire FRT21GNH
- Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21GNHD0 FRT21GNH R134a almond FRT21GNHW0 FRT21GNH R134a white MARKET North America WIRING DIAGRAM - # 193832 OWNER’S GUIDE - # 218921600 SERVICE DATA SHEET - # 218755000 REFRIGERATOR Model No.
- Page 2 Publication No. FRT21GNH 5995321006 DOOR 04/99...
- Page 3 FRT21GNH Publication No. 5995321006 DOOR A = FRT21GNH (FRT21GNHD0) B = FRT21GNH (FRT21GNHW0) POS. NO PART NO DESCRIPTION 215608903 Gasket-frzr door,almond ,magnetic 215608913 Gasket-frzr door,white ,magnetic 218730610 Gasket-refr door,almond ,magnetic 218730609 Gasket-refr door,white ,magnetic 218658901 Panel-inner door,refr 5303281387 Rack-door,25.25" x 1.58" 5303007295 Support-door rack,RH 5303007297...
- Page 4 Publication No. FRT21GNH 5995321006 CABINET 58 4 P05B0328 04/99...
- Page 5 FRT21GNH Publication No. 5995321006 CABINET A = FRT21GNH (FRT21GNHD0) B = FRT21GNH (FRT21GNHW0) POS. NO PART NO DESCRIPTION 5304402655 Cover-fan 5303307351 Knob-damper control 5303001028 Nut,push-on 218722200 Damper-fan cover,black 218649000 Fan Blade,black 5303001388 Plug-button,white 5300157666 Bushing-motor mtg,(2) 5303205118 Bracket-motor mtg,front 218802800 Cover-evap coil 5303209814 Nut,"U"...
- Page 6 Publication No. FRT21GNH 5995321006 SHELVES 04/99...
- Page 7 FRT21GNH Publication No. 5995321006 SHELVES A = FRT21GNH (FRT21GNHD0) B = FRT21GNH (FRT21GNHW0) POS. NO PART NO DESCRIPTION 218651901 Mullion,almond 218651900 Mullion,white 218781002 Heater-mullion 218845602 Tapping Plate,mullion mtg ,(2) 218866101 Top Panel-refr 218909702 Divider,styrofoam ,w/foil tape 8* # 218878600 Harness-wiring,control/divider 218865900 Bottom Panel-frzr 215667501...
- Page 8 Publication No. FRT21GNH 5995321006 SYSTEM 04/99...
- Page 9 FRT21GNH Publication No. 5995321006 SYSTEM A = FRT21GNH (FRT21GNHD0) B = FRT21GNH (FRT21GNHW0) POS. NO PART NO DESCRIPTION 218657100 Condenser 5304406039 Spacer-tube,5/8 OD x 3" lg 5304406040 Spacer-tube,5/8 OD x 12" lg 5304406721 Spacer-cond tube,round ,5/8 OD x .81"lg 5304406722 Spacer-tube,5/8 OD x 2"...
-
Page 10: Wiring Schematic
Publication No. FRT21GNH 5995321006 WIRING SCHEMATIC 04/99... -
Page 11: Wiring Diagram
FRT21GNH Publication No. 5995321006 WIRING DIAGRAM # = Fast-moving Parts 04/99 * = Non-Illustrated Parts...
