PRODUCT NO.
BASE MODEL NO.
FRT21NNHB4
FRT21NNH
FRT21NNHD4
FRT21NNH
FRT21NNHQ4
FRT21NNH
FRT21NNHW4
FRT21NNH
MARKET
North America
WIRING DIAGRAM - # 193832
OWNER'S GUIDE - # 218972200
SERVICE DATA SHEET - # 218755000
101 MASTERS BLVD.
ANDERSON, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
black
R134a System
almond
R134a System
bisque
R134a System
white
Publication No.
5995337929
000515
-EN/SERVICE /ECL
357
REFRIGERATOR
VOLTS
115
115
115
115
REFRIGERATOR
Model No.
FRT21NNH
©2000 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRT21NNH
Summary of Contents for Frigidaire FRT21NNH
- Page 1 FACTORY PARTS CATALOG REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21NNHB4 FRT21NNH R134a System black FRT21NNHD4 FRT21NNH R134a System almond FRT21NNHQ4 FRT21NNH R134a System bisque FRT21NNHW4 FRT21NNH R134a System white MARKET North America WIRING DIAGRAM - # 193832 OWNER’S GUIDE - # 218972200 SERVICE DATA SHEET - # 218755000 REFRIGERATOR...
- Page 2 Publication No. FRT21NNH 5995337929 DOOR 05/00...
- Page 3 FRT21NNH Publication No. 5995337929 DOOR A = FRT21NNH (FRT21NNHB4) B = FRT21NNH (FRT21NNHD4) C = FRT21NNH (FRT21NNHQ4) D = FRT21NNH (FRT21NNHW4) POS. NO PART NO DESCRIPTION 215608923 A - - - Gasket-frzr door,black ,magnetic 215608913 - B C D Gasket-frzr door,white ,magnetic 218730622 A - - - Gasket-refr door,black ,magnetic...
- Page 4 Publication No. FRT21NNH 5995337929 CABINET 05/00...
- Page 5 FRT21NNH Publication No. 5995337929 CABINET A = FRT21NNH (FRT21NNHB4) B = FRT21NNH (FRT21NNHD4) C = FRT21NNH (FRT21NNHQ4) D = FRT21NNH (FRT21NNHW4) POS. NO PART NO DESCRIPTION 5304402655 A B C D Cover-fan 5303307351 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 218722200...
- Page 6 Publication No. FRT21NNH 5995337929 CABINET 05/00...
- Page 7 FRT21NNH Publication No. 5995337929 CABINET A = FRT21NNH (FRT21NNHB4) B = FRT21NNH (FRT21NNHD4) C = FRT21NNH (FRT21NNHQ4) D = FRT21NNH (FRT21NNHW4) POS. NO PART NO DESCRIPTION 218916406 A - - - Grille/Kickplate,black ,w/fasteners 218916405 - B - - Grille/Kickplate,almond ,w/fasteners 218916408 - - C - Grille/Kickplate,bisque ,w/fasteners...
- Page 8 Publication No. FRT21NNH 5995337929 SHELVES 05/00...
- Page 9 FRT21NNH Publication No. 5995337929 SHELVES A = FRT21NNH (FRT21NNHB4) B = FRT21NNH (FRT21NNHD4) C = FRT21NNH (FRT21NNHQ4) D = FRT21NNH (FRT21NNHW4) POS. NO PART NO DESCRIPTION 218651902 A - - - Mullion,black 218651901 - B - - Mullion,almond 218651903 - - C - Mullion,bisque 218651900 - - - D...
- Page 10 Publication No. FRT21NNH 5995337929 SYSTEM 05/00...
- Page 11 FRT21NNH Publication No. 5995337929 SYSTEM A = FRT21NNH (FRT21NNHB4) B = FRT21NNH (FRT21NNHD4) C = FRT21NNH (FRT21NNHQ4) D = FRT21NNH (FRT21NNHW4) POS. NO PART NO DESCRIPTION 218657100 A B C D Condenser 5304406039 A B C D Spacer-tube,5/8 OD x 3" lg 5304406040 A B C D Spacer-tube,5/8 OD x 12"...
-
Page 12: Wiring Schematic
Publication No. FRT21NNH 5995337929 WIRING SCHEMATIC 05/00... -
Page 13: Wiring Diagram
FRT21NNH Publication No. 5995337929 WIRING DIAGRAM W193832 # = Fast-moving Parts 05/00 * = Non-Illustrated Parts...
