Frigidaire FRT21G3H Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT21G3H
  6. Parts catalog
Frigidaire FRT21G3H Parts Catalog

Frigidaire FRT21G3H Parts Catalog

Top-mount refrigerator
Hide thumbs

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet
Installation Instructions 240568301
N05L00004.eps N05DBDCKA0.eps N05BBAABA17.eps N05SAAAEF18.eps
N05CAAAAA30.eps
240398801.eps 240398601.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
FRT21G3HQ0 FRT21G3HQ1 FRT21G3HW0 FRT21G3HW1
R134a
R134a
R134a
bisque
bisque
white
115
115
115
240398801
240398801
240398801
241857200
241857200
241857200
North America North America North America North America
241615440
241615440
241615440
240379018
240379018
240379018
240568301
240568301
Publication No.
5995500989
07/09/28
(EN/SERVICE/RLF)
137
Copyright
R134a
white
115
240398801
241857200
241615440
240379018
240568301
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21G3H
©
All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21G3H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT21G3H

Summary of Contents for Frigidaire FRT21G3H

  • Page 1 Product No. FRT21G3HQ0 FRT21G3HQ1 FRT21G3HW0 FRT21G3HW1 Series R134a R134a R134a R134a Color bisque bisque white white Volts Wiring Diagram 240398801 240398801 240398801 240398801 Owner's Guide 241857200 241857200 241857200 241857200 Market North America North America North America North America Energy Guide 241615440 241615440 241615440...
