Frigidaire FRT21G4B Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT21G4B
  6. Factory parts catalog
Frigidaire FRT21G4B Factory Parts Catalog

Frigidaire FRT21G4B Factory Parts Catalog

Top mount r134a series
Hide thumbs Also See for FRT21G4B:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT21G4BQ4
FRT21G4B
FRT21G4BW4
FRT21G4B
MARKET
North America
WIRING DIAGRAM - # 240379010
OWNER'S GUIDE - # 240400106
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995379798
021016
-EN/SERVICE/KHB
357
FACTORY
PARTS CATALO
VOLTS
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT21G4B
©2002 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21G4B and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT21G4B

Summary of Contents for Frigidaire FRT21G4B

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT21G4BQ4 FRT21G4B R134a bisque FRT21G4BW4 FRT21G4B R134a white MARKET North America WIRING DIAGRAM - # 240379010 OWNER’S GUIDE - # 240400106 SERVICE DATA SHEET - # 240379010 TOP MOUNT REFRIGERATOR Model No.
  • Page 2 Publication No. FRT21G4B 5995379798 DOOR 10/02...
  • Page 3 FRT21G4B Publication No. 5995379798 DOOR A = FRT21G4B (FRT21G4BQ4) B = FRT21G4B (FRT21G4BW4) POS. NO PART NO DESCRIPTION 240514607 Gasket,seal ,white ,frzr door ,magnetic 240514608 Gasket,seal ,white ,refr door ,magnetic 240534901 Rack-door 240534701 Rack-door,4A 240337703 Door-dairy,w/o graphics ,clear 240534801 Rack-door 240381302 Plug-button,bisque ,hinge brg hole ,(2) 240381301...
  • Page 4 Publication No. FRT21G4B 5995379798 CABINET 10/02...
  • Page 5 FRT21G4B Publication No. 5995379798 CABINET A = FRT21G4B (FRT21G4BQ4) B = FRT21G4B (FRT21G4BW4) POS. NO PART NO DESCRIPTION 240355402 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240313606 Cover-evap coil 240371303 Seal, insulation, 53.23 in.
  • Page 6 Publication No. FRT21G4B 5995379798 SHELVES 10/02...
  • Page 7 FRT21G4B Publication No. 5995379798 SHELVES A = FRT21G4B (FRT21G4BQ4) B = FRT21G4B (FRT21G4BW4) POS. NO PART NO DESCRIPTION 215667501 Tray,ice cube ,plastic 240358003 Shelf,freezer ,full-width ,wire 5303299664 Spacer,shelf 240380202 Diffuser,air ,top 240362601 Diffuser,air ,bottom 14 # 240505801 Switch,light/lamp 240436702 Light Bulb, A-15, clear, 40 W, 120 V, miniature 241500701 Socket-light/lamp 240368101...
  • Page 8 Publication No. FRT21G4B 5995379798 SYSTEM 10/02...
  • Page 9 FRT21G4B Publication No. 5995379798 SYSTEM A = FRT21G4B (FRT21G4BQ4) B = FRT21G4B (FRT21G4BW4) POS. NO PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240496101 Wiring Harness,machine compt, w/electric cord 6* # 240388701 Wiring Harness,control box 6* # 240524701 Wiring Harness,freezer section 14 # 5303918247 Defrost Heater Kit...

  • Page 10: Wiring Schematic

    Publication No. FRT21G4B 5995379798 WIRING SCHEMATIC 10/02...

  • Page 11: Wiring Diagram

    FRT21G4B Publication No. 5995379798 WIRING DIAGRAM # = Fast-moving Parts 10/02 * = Non-Illustrated Parts...

This manual is also suitable for:

Frt21g4bq4Frt21g4bw4
