Frigidaire FRT21G4B Factory Parts Catalog
Frigidaire FRT21G4B Factory Parts Catalog

Frigidaire FRT21G4B Factory Parts Catalog

Top-mount refrigerator r134a series
Hide thumbs Also See for FRT21G4B:

Advertisement

Quick Links

N05L00006.eps N05DAACKA1.eps N05BBAABA17.eps N05SAAAEF14.eps
N05CABBAB6.eps
240398801.eps 240398601.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FRT21G4BQN FRT21G4BWC FRT21G4BWN
Series
R134a
Color
bisque
Volts
115
Wiring Diagram
240398801
Owner's Guide
240400112
Market
North America North America North America
Energy Guide
218791400
Service Data Sheet
240379014
Installation Instructions 240568300
Publication No.
5995428728
05/02/09
(EN/SERVICE/WC)
390
R134a
R134a
white
white
115
115
240398801
240398801
240400112
240400112
218791400
218791400
240379014
240379014
240568300
240568300
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21G4B
©
Copyright
2005 Home Pr
All rights reserved.
oducts, Inc.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT21G4B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Frigidaire FRT21G4B

  • Page 1 Product No. FRT21G4BQN FRT21G4BWC FRT21G4BWN Series R134a R134a R134a Color bisque white white Volts Wiring Diagram 240398801 240398801 240398801 Owner's Guide 240400112 240400112 240400112 Market North America North America North America Energy Guide 218791400 218791400 218791400 Service Data Sheet 240379014 240379014 240379014 Installation Instructions 240568300...
  • Page 2 Publication No: 5995428728 FRT21G4B DOOR N05DAACKA1 02/05...
  • Page 3 FRT21G4B Publication No: 5995428728 DOOR Model Index: A FRT21G4B (FRT21G4BQN) B FRT21G4B (FRT21G4BWC) C FRT21G4B (FRT21G4BWN) POS. NO PART NO. DESCRIPTION 240514607 A B C Gasket, seal, white, frzr door, magnetic 240514608 A B C Gasket, seal, white, refr door, magnetic 240534901 A B C Rack-door...
  • Page 4 Publication No: 5995428728 FRT21G4B CABINET N05BBAABA17 02/05...
  • Page 5 FRT21G4B Publication No: 5995428728 CABINET Model Index: A FRT21G4B (FRT21G4BQN) B FRT21G4B (FRT21G4BWC) C FRT21G4B (FRT21G4BWN) POS. NO PART NO. DESCRIPTION 240355402 A B C Cover-fan 240367001 A B C Knob-damper control 5303001028 A B C Nut, push-on 241523701 A B C Damper-fan cover 5308000010 A B C...
  • Page 6 Publication No: 5995428728 FRT21G4B CABINET N05BBAABA17 02/05...
  • Page 7 FRT21G4B Publication No: 5995428728 CABINET Model Index: A FRT21G4B (FRT21G4BQN) B FRT21G4B (FRT21G4BWC) C FRT21G4B (FRT21G4BWN) POS. NO PART NO. DESCRIPTION 5303316859 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin 241574607 A B C Cover-access, w/label 241500301 A B C Screw, hex washer head, 8-18AB x 0.500...
  • Page 8 Publication No: 5995428728 FRT21G4B SHELVES N05SAAAEF14 02/05...
  • Page 9 FRT21G4B Publication No: 5995428728 SHELVES Model Index: A FRT21G4B (FRT21G4BQN) B FRT21G4B (FRT21G4BWC) C FRT21G4B (FRT21G4BWN) POS. NO PART NO. DESCRIPTION 215667501 A B C Tray, ice cube, plastic 240358003 A B C Shelf, freezer, full-width, wire 5303299664 A B C Spacer, shelf 240545901 A B C...
  • Page 10 Publication No: 5995428728 FRT21G4B SYSTEM N05CABBAB6 02/05...
  • Page 11 FRT21G4B Publication No: 5995428728 SYSTEM Model Index: A FRT21G4B (FRT21G4BQN) B FRT21G4B (FRT21G4BWC) C FRT21G4B (FRT21G4BWN) POS. NO PART NO. DESCRIPTION 240444401 A B C Condenser, dynamic 218944001 A B C Drier-filter, R134a System 240581701 A B C Harness-wiring, machine compt 6* # 240388701 A B C...
  • Page 12: Wiring Schematic

    Publication No: 5995428728 FRT21G4B WIRING SCHEMATIC 02/05...
  • Page 13: Wiring Diagram

    FRT21G4B Publication No: 5995428728 WIRING DIAGRAM 02/05 # Functional Parts * Non-Illustrated Parts...

This manual is also suitable for:

Frt21g4bqnFrt21g4bwcFrt21g4bwn
