WRL Instruction Manual
The daily rainfall register
on the last day of each month at midnight. The term rainfall register is never zeroed automatically, it
must be manually zeroed through the TWI_LOG calibration routine or by pressing last and clear on
the display at the same time.
Report Flag
The report flag selects the format of the RS-232 output and may be changed via the display using
the print set routine or by using the TWI_LOG program calibration routine (F5) item 16 report flag.
(normally used when outputting directly to a printer)
SETTING MIN/MAX
0 OFF
1 ON
2 OFF
3 ON
4 OFF
5 ON
6 OFF
7 ON
When rain rate is off, term rain is substituted.
Min/Max, when selected outputs at midnight the minimum and maximum value for the day. The
report function must be on in order for the output to occur. This function must also be on if you want
the minimum and maximum to be logged to memory.
Form Feed, when selected sends a form-feed character at midnight, which is normally desirable if a
printer is directly hook up to the RS-232 interface.
Rainfall rate, when selected outputs rainfall rate instead of term rain in the report function.
Special Key Functions
Select + Report = Time Set Function
Select + Scale = Calibration Set Function
Select + Average = Printer Set Function
Select + Humidity Hold = Humidity Calibration Set
Select + Time Hold = Logging mode
Clear + Last = Clears Last Rain
Select + Last = Enters Rainfall History Mode
Clear + Maximum = Clears all Maximums and Minimums
Clear + Minimum = Clears all Maximums and Minimums
Clear +Scale +Average = Performs a cold boot
Windchill + Comfort =
Keys must be pressed precisely at the same time to perform the desired function.
Texas Weather Instruments, Inc.
is zeroed every day at midnight. The monthly rainfall register is zeroed
FORM FEED
OFF
OFF
OFF
ON
OFF
OFF
OFF
ON
Dewpoint
RAIN RATE
OFF
OFF
OFF
OFF
ON
ON
ON
ON
