WRL Instruction Manual
There are two settings that will affect the deposition of data. The first, report interval , determines
how often the WRL will automatically dump data to the RS-232 port. The second, log interval,
determines how often the unit saves data to its internal memory.
Pressing select and average at the same time puts the unit into print set mode. The unit first
displays the report interval in number of hours between lines of printed information. Press the
maximum and minimum keys to change display.
Pressing select a second time displays the number of minutes between lines of information. Press
the maximum and minimum keys to change the display.
Press select a third time, and the minimum/maximum and form feed options 0 through 7 may be
selected as illustrated in the table below:
SETTING MIN/MAX
0
1
2
3
4
5
6
7
Press select a fourth time to select the baud rate of the serial output. Press the maximum and
minimum keys to change the display.
Press select a fifth time to select log interval hours. The log interval tells the Weather Report to
send data to the internal memory and at what interval to do so. Press the maximum or minimum to
change the display.
Press select a sixth time to select the log interval minutes. Press the maximum or minimum to
change the display.
Press select a seventh time and a number between 0 and 255 will appear in the pressure/humidity
window which represents output options. Enter the proper option number by pressing the
maximum or the minimum keys. The output options control the selection of such things as AM PM,
wind speed knots, auxiliary display and average wind speed output.
reference section called control options for more information, page 20.)
Press select a eighth time and the unit will return to a normal display.
Texas Weather Instruments, Inc.
OFF
ON
OFF
ON
OFF
ON
OFF
ON
When rain rate is off, term rain is substituted.
FORM FEED RAIN RATE
OFF
OFF
OFF
ON
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
ON
ON
ON
ON
(Look at the first item in the
