WRL Instruction Manual
at a time, press the page up or down keys to display one screen of data at a time, press the home
or end key to go to the top or bottom of the file. The delete key takes all records prior to that
displayed at the top of the screen and transfers that data to an archive file
extension ??? will be the same as the unit number. The data that is archived is removed from the
current display and log file.
Pressing F4 purges any duplicate data written on disk.
Pressing F5 -the calibration screen.
Inx Value Description
1 85 temp:aux
2 65 temp: inside
3 73 temp: outside
4 29.92 barometric pressure
5 0 elevation
6 0.750 MVP @ 0.0% HR
7 3.255 MVP @ 73.3% HR
8 8 wind dir. offset
9 2 rain inc flag
10 0.01 rain inc value
11 0.00 rain fall: daily
12 0.00 rain fall: monthly
13 0.00 rain fall: term
14 0 report interval HI
15 0 report interval LO
16 0 report Min/Max :Off
17 4 report end of day
18 0 report interval Units: M:S:
19 0 report character: r
enter parameter index: ?
Note: This screen and its index numbers will vary depending on what options are installed.
Any item in this index can be changed by:
(1)entering the index number
(2)entering the new value
(3)entering Y to set the new value or N to reject the new value.
1) Aux temperature calibration
2) Inside temperature calibration
3) Outside temperature calibration
4) Barometric pressure calibration
5) Elevation correction ( not used)
6)1st humidity sensor calibration factor
Texas Weather Instruments, Inc.
Inx Value Description
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
arc_log.???
94 clock years
11 clock month
22 clock day of month
2 clock day of week::Mon:
11 clock hours
24 clock minutes
54 clock seconds
0 log interval hrs
30 log interval minutes
0 Scale: 0=FPS 1=CGS
0 ID number
8 POR Counter
0 RR Interval , sec
0 Wsp units : MPH
1 Time dispaly : AMPM
1 aux Temp
1 Wsp/Wdir
4 baud rate: 2400
file. The
