WRL Instruction Manual
in 30.04R the "R" denotes rising pressure)
Sample
5:15 07/24/90 SSE 04MPH 052F 069F 078F 099% 30.04R 00.19"D 01.38"M 11.78"T
r- Unit responds with current conditions. The term rain is present rather than the rainfall rate. (Note:
in 30.04F the "F" denotes falling pressure, a "S" character denotes steady pressure.)
Sample
5:15 07/24/90 SSE 04MPH 052F 069F 078F 099% 30.04F 00.19"D 01.38"M 00.72"R
K- Unit responds with current calculated values, for dew point, Windchill and heat index.
The following commands respond if the WRL has logged data in memory.
T- Data logger top, moves pointer to the top of the data records, then sends data
N- Data logger next, moves pointer to the next data record, then sends data.
A- Data logger again, sends same data again.
P- Data logger previous, moves pointer to the previous data record, then sends data.
B- Data logger bottom, moves pointer to the bottom of the data records.
Sample
01/01 23:00 052F 053F 085F 000% 29.92" 00.00"D 000MPH NNE
date time temp
Twi_Log Program
The TWI_LOG program. TWI_LOG is an IBM PC software utility which enables the user with
special applications to communicate and set various functions of the WRL. Insert the TWI_LOG
diskette into your disk drive and type TWI_LOG then press enter.
Note: TWI LOG is no longer sent with the weather stations. The TWI Cal Windows program has
replaced TWI_LOG and is included with the weather station. If for some reason you still need the
TWI_LOG program it is available on our website at www.texas-weather.com.
The first screen of the program will look this:
1 Com1
2 Com2
3 Modem
enter index of station name: ?
Pressing selection 1 accesses the WRL, if it is plugged into com1.
Pressing selection 2 accesses the WRL if it is plugged into com2.
Texas Weather Instruments, Inc.
humidity bp rain wind speed direction
