Summary of Contents for HOLMS SB
- Page 1 Operating instructions Sand Spreading bucket 1,0 m Applicable from machine n.o: 14800 Box 924 S-591 29 Motala Sweden +46 141 22 41 00 +46 141 22 41 90 Original: English © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213. English...
-
Page 3: Table Of Contents
Adjusting the discharge roller......14 Manual Control..........14 Electrical control..........15 Service and maintenance...........16 Every 20 operating hours ........16 Adjusting/replacing rubber deflector ....18 Adjusting/replacing end seal ......18 Adjusting roller cleaning brushes ......18 Removing protective covers......19 Troubleshooting............20 Subject index..............21 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213. -
Page 4: Warning Labels
There are several specific warning labels on this product; see the descriptions below. Make sure that you understand the implications of these labels before using the product. Clean/replace warning labels if they are illegible or are missing. Contact you Holms dealer if you require new labels. - Page 5 Use the marked loops when transporting the tool (warning label 1530056) When transporting the tool, use the marked loops to secure the tool during transit. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213.
- Page 6 Use approved lifting devices only. Risk of crushing - mind your hands (warning label 1530060) Mind your hands and keep them away from this area whilst the tool is in use. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213.
-
Page 7: Safety
Unauthorised persons do not use the machine or remain within the machine’s working area during its operation or maintenance. The carrier is suitable for use with the machine (hydraulic oil flow, stability, etc.). © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213. - Page 8 MATERIAL DAMAGE RESULTING FROM THE USE OF NON APPROVED SPARE PARTS OR MODIFICATIONS When ordering spare parts, or otherwise contacting Holms or your local dealer, always specify the machine type and its serial number. (Specified on the product’s machine plate.)
-
Page 9: Product Date
Minimum available hydraulic pressure (bar) 140V Hydraulic top link, max. stroke length (mm) 1009 Hydraulic top link, min. stroke length (mm) Hydraulic top link, stroke length (mm) 1.Centre of gravity, dimension A, B and C © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213. -
Page 10: Machine Plate
Serial No. • Year of manufacture • Weight • code of the person who assembled the bucket (Assembler) • code of the person who checked the bucket on delivery (Checked). 2.Machine plate © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213. -
Page 11: Product Description
Product description Sand spreading bucket SB 1.0 is adapted for three-point linkage. SB 1,0 (figure 5) can be used for spreading: • sand with a diameter of 0-8mm • crushed rock with a diameter of 2-8mm • road salt The sand spreading bucket is primarily intended for road gritting in winter. -
Page 12: Transport And Storage
In the event of storage and prolonged periods of 6.Lifting the sand spreading bucket, inactivity, the bucket must be cleaned and lubricated as lifting eye per instructions under “Service and maintenance” on page 16. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213. -
Page 13: Connection To Carrier
9.The discharge roller's direction of rotation Operating instructions Operator settings In order to achieve good spreading, the sand spreading bucket's discharge opening should be around 0.5 m above the ground. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213. -
Page 14: Spreading Crushed Rock
1. Switch the motor on. 2. Turn the hand wheel on the right (see position figure 11), until the desired speed is set. Lock the speed by turning the hand wheel on the left. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213. -
Page 15: Electrical Control
Normally the start position is around 25. Normal po- sition: end position anticlockwise. 4. Screws no. 1 and 4 are never normally touched. If you wish to perform further adjustments, please contact Holms. 13.Box for speed cabling © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213. -
Page 16: Service And Maintenance
Hydraulic oil can cause allergic reactions. If you get hydraulic oil on your skin, wash the area 16.Lubrication points, non-motor side (bucket with mixer) immediately to remove all traces of the oil. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213. - Page 17 (see figure 19). The brush must only touch the roller with the brush end. Adjust as necessary (see “Adjusting roller cleaning brushes” on page 18). 18.End seal • There must be no loose screw joints. 19.Roller cleaning brush © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213.
-
Page 18: Adjusting/Replacing Rubber Deflector
2. Adjust the brushes by moving the holders in their 21.Adjusting/replacing end seal tracks. The brushes should just touch the roller. 3. Once all the brushes have been adjusted, tighten the screw joints. Roller Brush 22.Adjusting roller cleaning brushes © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213. -
Page 19: Removing Protective Covers
Removing protective covers To remove a protective cover, undo both screw joints (see figure 23) and lift off the cover. 23.Removing protective covers © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213. -
Page 20: Troubleshooting
1. Remove the protective cover on the left side (see “Adjusting roller cleaning brushes” on page 18). 2. Check the coupling. Erratic discharge volume: 1. Adjust the rubber deflector so that the gap is the same along its entire length. © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213. -
Page 21: Subject Index
12 product data 4 product description 11 produktdata 9 protective covers 19 replacing end seal 18 rubber deflector 18 roller cleaning brushes adjusting 18 rubber deflector adjusting 18 replacing 18 service 16 © HOLMS INDUSTRI AB, ALL RIGHTS RESERVED 090213.
