Dealer Setup
& Adjustment Instructions
Coronet / 2400 / RE 200 Series Tractors and Mowers
Refer to the Dealer Setup & Adjustment binder Index for a
complete listing of products covered by this document.
Mfg. No. Description
Tractors
1694610
Coronet
1694611
Coronet
1694612
Coronet (CE)
1694613
2413H
1694614
2413H (CE)
1694615
RE1330
1694616
RE1330 (CE)
1695508
Coronet
1695509
RE1330
1695510
Coronet
2690244
Coronet & 30" Mower
2690245
Coronet & 34" Mower
2690246
Coronet & 30" Mower (CE)
2690247
2413H & 30" Mower
2690248
2413H & 30" Mower (CE)
2690249
RE1330 & 30" Mower
2690250
RE1330 & 30" Mower (CE)
2690800
Coronet & 30" Mower
2690801
RE1330 & 30" Mower
2690802
Coronet & 34" Mower
2691012-00
Coronet & 30" Mower
2691019-00
Coronet & 30" Mower
Mowers
1692543
30" Mower Deck
1692545
34" Mower Deck
1694053
30" Mower Deck
1694191
34" Mower Deck
1694511
30" Mower Deck (CE)
1694537
30" Mower Deck
ATTENTION SETUP PERSONNEL:
The safety warnings provided in this guide and in
the operator's manual included with the unit contain
important information that must be obeyed when
assembling, setting-up, operating, servicing, trans-
porting, or storing the unit.
These warnings are highlighted by the safety alert triangle sym-
bol shown above, which signifies that an important safety mes-
sage is being provided.
You must read, understand, and follow these warnings and
instructions, and use safe shop and work practices at all
times while working on or around this unit and all other
outdoor power equipment.
Sections and items denoted by the Setup symbol
provide the information necessary to fully assemble,
test, and prepare the units described above for
delivery to your customers.
Additional information concerning functional tests,
general adjustment procedures, and the location of
normal lubrication points are included in these
instructions.

TABLE OF CONTENTS:

SAFETY RULES .................................................................2
Quick Setup List ................................................................3
Uncrating ............................................................................4
Battery Activation & Installation ......................................4
Tractor Assembly ..............................................................5
Steering Wheel Assembly (CE only) ................................5
Check Fluid levels .............................................................6
Fill and Check Engine Oil.................................................6
Check Transmission Oil Level .........................................6
Reduce and Check Tire Pressure ....................................6
Mower Assembly ...............................................................7
Install Deflector ................................................................7
Torque Mower Blade Bolts...............................................7
Install the Mower Deck.....................................................8
Mower Deck Leveling ........................................................9
Side-to-Side Leveling .......................................................9
Front-to-Back Leveling ...................................................10
Lubrication .......................................................................10
Perform Safety Checks ...................................................12
Functional Tests.............................................................12
Mower Blade Stopping Check........................................12
Seat Switch Connection .................................................12
Safety Interlock System .................................................12
Burnishing the Electric PTO Clutch...............................12
Transmission Purging.....................................................13
Seat Adjustment ..............................................................14
Neutral Adjustment .........................................................14
Steering Gear Adjustment ..............................................14
Brake Spring Adjustment ...............................................15
Transmission Maintenance ............................................17
Transmission Oil Change ...............................................18
Transmission Drive Belt Replacement ..........................18
Mower Belt Replacement ................................................19
1
1727385
Revision C
