OPERATOR'S
MANUAL
24HP Zero-Turn Riders
Mfg. No.
Description
5900660
ZT3000B2444, Simplicity 24HP B&S ZT3000 Zero-Turn Rider with 44" Mower
5900662
ZT3000B2450, Simplicity 24HP B&S ZT3000 Zero-Turn Rider with 50" Mower
5900684
ZT3000B2450CE, Simplicity 24HP B&S ZT3000 Zero-Turn Rider with 50" Mower
(CE/Export)
5900681
355ZB2444, Snapper 24HP B&S 355Z Zero-Turn Ridier with 44" Mower
5900682
355ZB2450, Snapper 24HP B&S 355Z Zero-Turn Ridier with 50" Mower
5900685
355ZB2450CE, Snapper 24HP B&S 355Z Zero-Turn Ridier with 50" Mower
(CE/Export)
Form No. 5101066
Revision 01
Rev.Date 8/2007
TP 100-7327-01-CH-SMN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 24HP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Simplicity 24HP

Summary of Contents for Simplicity 24HP

  • Page 1 MANUAL 24HP Zero-Turn Riders Mfg. No. Description 5900660 ZT3000B2444, Simplicity 24HP B&S ZT3000 Zero-Turn Rider with 44” Mower 5900662 ZT3000B2450, Simplicity 24HP B&S ZT3000 Zero-Turn Rider with 50” Mower 5900684 ZT3000B2450CE, Simplicity 24HP B&S ZT3000 Zero-Turn Rider with 50” Mower...
  • Page 2 THIS PAGE INTENTIONALLY BLANK (FOR PLACEMENT ONLY - DO NOT PRINT)
  • Page 3 Thank you for purchasing this quality-built product. We’re pleased that you’ve placed your confidence in the Simplicity and Snapper brand. When operated and maintained according to the instructions in this manual, your product will provide many years of dependable service.

  • Page 4: Table Of Contents

    Table of Contents Safety Rules & Information...2 Identification Numbers ...8 Safety Decals ...9 Safety Interlock System ...10 Safety Icons ...11 Features & Controls ...12 Control Functions ...12 Operation ...14 General Operating Safety ...14 Checks Before Starting ...14 Starting the Engine ...15 Stopping the Rider &...

  • Page 5: Safety Rules & Information

    Safety Rules & Information Read the Manual The operator’s manual contains important safety information you need to be aware of BEFORE you operate your unit as well as DURING operation. Safe operating techniques, an explanation of the product’s features and controls, and maintenance information is included to help you get the most out of your equipment investment.

  • Page 6: Slope Operation

    Thrown Objects This unit has spinning mower blades. These blades can pick up and throw debris that could seriously injure a bystander. Be sure to clean up the area to be mowed and remove objects that could be thrown by the blade BEFORE you start mowing.

  • Page 7: Enclosed Areas

    Safety Rules & Information Retaining Walls, Drop-offs, and Water Retaining walls and drop-offs around steps and water are a common hazard. Give yourself a minimum of two mower widths of clearance around these hazards and hand-trim with a walk behind mower or string trimmer. Wheels dropping over retaining walls, edges, ditches, embankments, or into water can cause rollovers, which may result in serious injury, death, or drowning.

  • Page 8: General Operation

    Read these safety rules and follow them closely. Failure to obey these rules could result in loss of control of unit, severe personal injury or death to you, or bystanders, or damage to property or equipment. This mowing deck is capable of amputating hands and feet and throwing objects. The triangle in text signifies important cautions or warnings which must be followed.

  • Page 9: Safety Rules And Information

    Safety Rules and Information SLOPE OPERATION Slopes are a major factor related to loss-of-control and tip-over accidents, which can result in severe injury or death. Operation on all slopes requires extra caution. If you cannot back up the slope or if you feel uneasy on it, do not operate on it.

  • Page 10: Service And Maintenance

    SERVICE AND MAINTENANCE Safe Handling of Gasoline 1. Extinguish all cigarettes, cigars, pipes, and other sources of ignition. 2. Use only approved gasoline containers. 3. Never remove the gas cap or add fuel with the engine running. Allow the engine to cool before refueling.

  • Page 11: Identification Numbers

    H. Power Rating in Kilowatts I. Mass of Unit in Kilograms J. Sound Power in Decibels * This unit complies with European Harmonized Lawn Mower Standard EN 836, European Machinery Directive 98/37/EC, and European EMC Directive 2004/108/EEC * Tested according to 2000/14/EC...

  • Page 12: Safety Decals

    SAFETY DECALS This unit has been designed and manufactured to provide you with the safety and reliability you would expect from an industry leader in outdoor power equipment manufacturing. Although reading this manual and the safety instructions it contains will provide you with the necessary basic knowledge to operate this equipment safely and effectively, we have placed several safety labels on the unit to remind you of this important...

  • Page 13: Safety Interlock System

    Safety Interlock System NORTH AMERICAN MODELS ONLY: SAFETY INTERLOCK SYSTEM This unit is equipped with safety interlock switches. These safety systems are present for your safety, do not attempt to bypass safety switches, and never tamper with safety devices. Check their operation regularly.

  • Page 14: Safety Icons

    Safety Icons The alert symbol is used to identity safety information about hazards that can result in personal injury. A signal word (DANGER, WARNING, or CAUTION) is used with the alert symbol to indicate the likelihood and the potential severity of the injury. In addition, a hazard icon may be used to represent the type of hazard.

  • Page 15: Features & Controls

    Features & Controls CONTROL FUNCTIONS The information below briefly describes the function of individual controls. Starting, stopping, driving, and mowing require the combined use of several controls applied in specific sequences. To learn what combination and sequence of controls to use for various tasks see the OPERATION section. Ground Speed Control Levers These levers control the ground speed of the rider.
  • Page 16 Hour Meter The hour meter measures the number of hours the key has been in the RUN position. Note: The hour meter will register the passage of time when the key is in the RUN position, even if the engine is not running.

  • Page 17: Operation

    Operation GENERAL OPERATING SAFETY Before first time operation: • Be sure to read all information in the Safety and Operation sections before attempting to operate this tractor and mower. • Become familiar with all of the controls and how to stop the unit.

  • Page 18: Starting The Engine

    WARNING If you do not understand how a specific control functions, or have not yet thoroughly read the FEATURES & CONTROLS section, do so now. Do NOT attempt to operate the tractor without first becoming familiar with the location and function of ALL controls.

  • Page 19: Zero Turn Driving Practice

    Operation ZERO TURN DRIVING PRACTICE The lever controls of the Zero Turn rider are responsive, and learning to gain a smooth and efficient control of the rider’s forward, reverse, and turning movements will take some practice. Spending some time going through the maneuvers shown and becoming familiar with how the unit accelerates, travels, and steers —...

  • Page 20: Advanced Driving

    Practice Turning Around a Corner While traveling forward bring one handle gradually back toward neutral. Repeat several times. NOTE: To prevent pivoting directly on the tire tread, it is best to keep both wheels going at least slightly forward. Executing Turns Figure 6.

  • Page 21: Mower Removal & Installation

    Operation Figure 9. Mower Belt Routing A. Arbor Pulleys B. Back-Side Idlers C. PTO Pulley D. Belt Tension Release Lever MOWER REMOVAL AND INSTALLATION NOTE: Perform mower deck installation and removal on a hard flat surface such as a concrete floor. Removal 1.

  • Page 22: Mowing

    MOWING Before mowing, set the cutting height as described in the Troubleshooting, Adjustments & Service section. 1. Engage the parking brake. Make sure the PTO switch is disengaged and the motion control lever is in the NEUTRAL position. 2. Start the engine (see STARTING THE ENGINE). 3.

  • Page 23: Mowing Patterns

    Operation When and How Often to Mow The time of day and condition of the grass greatly affect the results you’ll get when mowing. For the best results, follow these guidelines: 1. Mow when the grass is between three and five inches high.

  • Page 24: Attaching A Trailer

    Proper Mulching Mulching consists of a mower deck which cuts and recuts clippings into tiny particles and which then blows them down INTO the lawn. These tiny particles decompose rapidly into by-products your lawn can use. UNDER PROPER CONDITIONS, your mulching mower will virtually eliminate noticeable clippings on the lawn surface.

  • Page 25: Regular Maintenance

    Regular Maintenance MAINTENANCE SCHEDULE & PROCEDURES The following schedule should be followed for normal care of your rider and mower. You will need to keep a record of your operating time. Determining operating time is easily accomplished by observing the elapsed time recorded by the hour meter.

  • Page 26: Lubrication

    LUBRICATION Lubricate the unit at the following lubrication points shown in Figure 16. Grease: • front caster wheel axles • front caster yokes • roller straps (deck lift pivots) • mower deck idler arm pivot • mower deck arbors Use grease fittings when present. Disassemble parts to apply grease to moving parts when grease fittings are not installed.

  • Page 27: Servicing The Mower Blades

    Regular Maintenance SERVICING THE MOWER BLADES Removing the Mower Blade CAUTION Avoid injury! Mower blades are sharp. • Always wear gloves when handling mower blades or working near blades. 1. See Figure 17. To remove the mower blade, wedge a wooden block between the mower blade and the mower deck housing to keep the mower blade from turning, then remove the mower blade and the mower blade retaining hardware.

  • Page 28: Balancing The Mower Blades

    Sharpening the Mower Blade CAUTION Avoid injury! Mower blades are sharp. • Always wear gloves when handling the mower blades. • Always wear safety eye protection when grinding. 1. Sharpen the mower blades with grinder, hand file, or electric blade sharpener. 2.

  • Page 29: Checking Tire Pressures

    Regular Maintenance CHECK TIRE PRESSURES Tire pressure should be checked periodically, and maintained at the levels shown in the chart. Note that these pressures may differ slightly from the “Max Inflation” stamped on the side-wall of the tires. The pressures shown provide proper traction, improve cut quality, and extend tire life.

  • Page 30: Change Engine Oil & Filter

    CHANGE ENGINE OIL & FILTER 1. Warm the engine by running for a few minutes. (Refer to the engine operator’s manual for oil & filter replacement instructions) 2. The oil drain hose (A, Figure 25) is located on the left side of the engine. Remove the oil drain hose from its storage position and re-position the oil drain hose over the side of the engine deck and place a small pan beneath it to catch the old...

  • Page 31: Check/Fill Transmission Oil

    Regular Maintenance CHECK / FILL TRANSMISSION OIL Oil Type: 20W-50 conventional detergent motor oil. 1. Check the oil level when the unit is cold. Raise the seat plate to gain access to the transmission oil reservoirs (A, Figure 26). The oil should be up to the “FULL COLD”...

  • Page 32: Battery Maintenance

    BATTERY MAINTENANCE Cleaning the Battery and Cables 1. Disconnect the cables from the battery, negative cable first (B, Figure 28). 2. Clean the battery terminals and cable ends with a wire brush until shiny. 3. Reinstall the battery and reattach the battery cables, positive cable first (see A, Figure 28) 4.

  • Page 33: Troubleshooting, Adjustments & Service

    Troubleshooting, Adjustments, & Service TROUBLESHOOTING While normal care and regular maintenance will extend the life of your equipment, prolonged or constant use may eventually require that service be performed to allow it to continue operating properly. The troubleshooting guide below lists the most common problems, their causes and remedies.

  • Page 34: Troubleshooting The Mower

    Rider Troubleshooting Continued. PROBLEM Engine runs, but rider will not drive. Rider drive belt slips. Brake will not hold. Rider steers or handles poorly. TROUBLESHOOTING THE MOWER PROBLEM Mower will not raise. Engine stalls easily with mower engaged. Excessive mower vibration. Excessive belt wear or breakage.

  • Page 35: Common Cutting Problems

    Troubleshooting, Adjustments, & Service TROUBLESHOOTING COMMON CUTTING PROBLEMS PROBLEM Streaking. Scalping. Stepped Cutting. Uneven Cutting. Stingers. CAUSE 1. Blades are not sharp. 2. Blades are worn down to far. 3. Engine speed is too slow. 4. Ground speed is too fast. 5.

  • Page 36: Seat Adjustment

    SEAT ADJUSTMENT The seat and ground speed control levers should be adjusted so that operator’s elbows are supported by the arm rests when his/her hands are on the controls, and the ground speed control levers can be moved through their full range of motion without contacting the operator’s legs.

  • Page 37: Speed Balancing Adjustment

    Troubleshooting, Adjustments, & Service SPEED BALANCING ADJUSTMENT WARNING DO NOT adjust the rider for a faster overall speed forward or reverse than it was designed for. If the rider veers to the right or left when the ground speed control levers are in the maximum forward or reverse position, the top speed of each of these levers can be balanced by turning the adjustment bolt(s) (A &...

  • Page 38: Parking Brake Adjustment

    PARKING BRAKE ADJUSTMENT 1. Disengage the PTO, stop the engine, engage the parking brake, and remove the key from the ignition. 2. Raise the seat plate to gain access to the parking brake components. 3. Measure the distance from the top of the brake spring rod (C, Figure 33) to the top of the lock nut (D) on both sides of the unit.

  • Page 39: Pto Clutch Adjustment

    Troubleshooting, Adjustments, & Service Figure 35. PTO Clutch Adjustment A. Adjustment Window (Qty. 3, one shown) B. Adjustment Nut PTO CLUTCH ADJUSTMENT Check the PTO clutch adjustment after every 100 hours of operation. Also perform the following procedure if the clutch is slipping or will not engage, or if a new clutch has been installed.

  • Page 40: Mower Deck Leveling

    MOWER DECK LEVELING Perform these adjustments on a flat level surface. SIDE-TO-SIDE LEVELING 1. With the mower installed, place the rider on a smooth, level surface such as a concrete floor. Turn the front wheels so they are straight. 2. Check for bent blades and replace if necessary. 3.

  • Page 41: Roller Bar Leveling

    Troubleshooting, Adjustments, & Service ROLLER BAR LEVELING (SELECT MODELS) The rollers on this Zero Turn unit are not intended to ride on the ground. DO NOT adjust rollers to ride on the ground. Rollers riding on the ground will damage turf and/or unit.

  • Page 42: Hydraulic Pump Drive Belt Replacement

    HYDRAULIC PUMP DRIVE BELT REPLACEMENT 1. Park the rider on a smooth, level surface such as a concrete floor. Disengage the PTO, engage the parking brake, turn off the engine, and remove the ignition key. 2. Remove the PTO drive belt (see MOWER BELT REPLACEMENT for removal instructions).

  • Page 43: Specifications

    For applicable manuals currently available for your model, contact our Customer Publications Department at 262-284-8519 (Simplicity) / 866-313-6682 (Snapper). Have the model and serial information for your machines available when phoning in your request. Technical manuals can be downloaded from www.simplicitymfg.com | www.snapper.com...
  • Page 44 Notes...
  • Page 45 Product Quick Specs: ENGINE: 24 HP* Briggs & Stratton Make Briggs & Stratton Model 44M777-0121-E1 Oil Capacity 4 US pt. (1.9 L) w/ Filter CHASSIS: Fuel Tank Capacity: 6.5 Gallons (24.6 L) Rear Wheels Tire Size: 20 x 8.00 -10 Inflation Pressure: 15 psi (1,03 bar) Front Wheels Tire Size: 11 x 4.00-5...
