Summary of Contents for X-Tronic 4020-PRO-X
-
Page 3: Table Of Contents
PLEASE READ THESE INSTRUCTIONS BEFORE USING THE NEW X-TRONIC MODEL #4020-PRO-X HOT AIR REWORK STATION TABLE OF CONTENTS Product Specifications............2 Package Contents .............2 Safety Precautions ............3 Unit Diagram ..............4 Initial Set-up ...............5 Features................7 Quick Change Nozzle Rack ..........7 Auto Cool Down / Standby Mode ........8 Celsius / Fahrenheit Conversion ........8... -
Page 4: Product Specifications
SPECIFICATIONS Model XTR-4020-PRO-X Power Consumption 1000 Watts Voltage AC 110V 60Hz Power Cord Type USA Type B - 3-Pin Grounded Plug Current ≤ 8 Amps Fuse 20 Amp Dimensions 9.0 L x 9.5” W x 5.5” H Weight 7.5 lbs Working Environment 32°F ~ 104°F / 0°C ~ 40°C... -
Page 5: Safety Precautions
SAFETY PRECAUTIONS 1. Always use a grounded outlet for the unit. 2. Always turn the power off and unplug the unit when not in use. 3. Never use the hot air gun near any flammable substance, material, or gas. 4. Never touch the metallic components of the hot air gun while the unit is on. -
Page 6: Unit Diagram
PANEL DIAGRAM 1. Set / Actual Air Flow Display 2. Actual Temperature Display 3. Set Temperature Display 4. Patented Quick Change Nozzle Rack & Nozzles 5. Temperature Adjustment Buttons 6. Power Switch 7. 4 Memory Preset Buttons 8. Function Set Button 9. -
Page 7: Initial Set-Up
INITIAL SET - UP 1. Place the hot air gun in the vertical position in the upright tower holder. Ensure the hot air gun is fully seated so the edge is resting against the base of the holder. See photo below. Hot Air Gun Correctly Seated in Upright Tower Holder... - Page 8 8. When the hot air gun is not in use always place it back in the vertical position in the upright tower holder. The hot air gun will go into Auto Cool Down mode and continue blowing air until the temperature gets back down to 100°C.
-
Page 9: Features
FEATURES QUICK CHANGE NOZZLE RACK With the patented Quick Change Nozzle Rack that is included, changing out hot air nozzles is quick and efficient. To Install a Nozzle 1. Center the hot air gun over the chosen nozzle in the Quick Change Nozzle Rack. -
Page 10: Auto Cool Down / Standby Mode
CALIBRATION FUNCTION When is it time to Calibrate your Hot Air Station? All X-Tronic Stations come with a high quality heating element in the hot air gun that is calibrated to within ±1.8°F/1.0°C of the temperature that is shown on the LED Display. While calibrating... - Page 11 The age of the heating element, the hours of use, and the temperature at which the hot air gun is regularly used will affect the life of the heating element and can cause fatigue. When a heating element begins to fatigue, the heat that is transferred to the blowing air from the heating element will begin to drop.
-
Page 12: Maintenance
MAINTENANCE REPLACING THE HOT AIR GUN HEATING ELEMENT Retaining Handle Discharge Cover - Tube Side 2 Heating Element Circuit & Mica Paper Board (inside) Handle Cover - Side 1 1. Turn off the unit and unplug it from the outlet. Allow the hot air gun to cool down to room temperature. -
Page 13: Troubleshooting
POSSIBLE SOLUTIONS Unit does not • Ensure that the outlet is functional. have power • Contact X-Tronic International for technical assistance - Contact information on back of manual Soldering Iron • This is expected behavior. The “rattle” is a small ball “Rattles”... -
Page 14: Warranty
(b) any product shipped outside of the United States, the District of Columbia or Canada, or (c) anyone who may have purchased it from someone other than X-Tronic International Inc.. Proof of purchase is required for in- warranty service. We recommend you promptly register this product on our website (www.XTronicUSA.com) to facilitate verification of the date of the original... - Page 15 WHAT DOES THIS WARRANTY NOT COVER? This limited warranty during the Warranty Period does not cover any damage due to: (a) improper use; (b) failure to follow the product instructions or to perform any preventive maintenance; (c) modifications; (d) unauthorized repair; (e) normal wear and tear that comes with household use;...
-
Page 16: Contact Information
Compliments please call or email us. Toll Free: 844-861-4762 Info@XTronicUSA.com Our Business Hours are: Monday - Thursday: 8am - 4pm CST Friday: 8am - Noon CST If you would like to shop for other X-Tronic International Products Please visit our website www.XTronicUSA.com...
