TRAMPOLINE AND ENCLOSURE
DISASSEMBLY INSTRUCTIONS
The disassembly is largely the reverse of the assembly steps. The following points should be noted:
Figure 1: The release clip on the mat itting
Release
Lever
Figure 2: The release clip on the mat itting (view
beneath mat edge)
Figure 3: Preferred rod bending technique
Springfree™ Trampoline Model SF90E Trampoline and Enclosure Assembly, Installation, Care, Maintenance and Use Instructions Version 6.4
Enclosure
First, remove the C-clips at the bottom of the
enclosure rods, then lift the bottom of the
enclosure rods out of their sockets in the frame.
Once the net is slack, pull the rods from the
pockets at the top of the net. The net will then
be lying around the trampoline as in Step 15,
Figure 15-B of the Trampoline and Enclosure
Assembly Instructions.
Push lever
towards mat
centre to
TO FOLD THE ENCLOSURE ROD
release ball
1. Remove the enclosure rod assembly from
the enclosure rod socket in the base of the
trampoline.
2. Remove the rod assembly from the rod
pocket at the top of the net.
3. Slide the white joiner up and fold the
enclosure rods.
Trampoline
1. To release each rod, push the clip lever
towards the mat centre, and hold (Figures
1 and 2). Then push the ball end of the rod
towards the mat centre to disengage it
from the socket (Figure 3).
2. Move around the trampoline releasing
every ifth rod.
3. Continue circling, releasing rods to the
right of the gap until all rods are released
(by working at the right of the gap rather
than the left, your knuckles have more
clearance).
4. Once the mat is free, the frame can be
disassembled.
Tip: One method to release a rod is to grip a pair
of rods with the right hand while releasing the
clip of the upper rod with the left hand. Now by
tightening the grip on the two rods the upper
rod ball slips out of the socket, while the rod is
still held irmly in the hand. From there, the rod
can be freed in a safe and controlled manner
(Figure 3).
WARNING: Never attempt to remove
an enclosure rod from its pocket or
disengage (unlock) the joiner while
the enclosure rod is under tension.
WARNING: Treat any loaded rod with
caution. Keep your face well clear of
any loaded rod.
WARNING: Do not attempt to
disassemble any frame components
before the mat and rods have been
removed. The frame and legs need to
remain assembled to carry the
rod loads.
