- Page 1 RFID Reader SSA-R1001V User Manual SSA-R1101V...
- Page 2 Samsung Techwin. Disclaimer Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility.
- Page 3 If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifi cations or attempted repair.) . When cleaning, do not spray water directly onto parts of the product. Doing so may cause fi re or electric shock.
- Page 4 safety information FCC Statement Caution : Any changes or modifi cations in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.
-
Page 5: Table Of Contents
contents PRODUCT INTRODUCTION Features What’s included At a Glance Cable Color Scheme Cable Selection INSTALLATION AND EXTERNAL Installation Precautions on installation CONNECTION External Connection INITIALIZATION Basic Operations OUTPUT FORMAT WIEGAND Output RS-232 Output TROUBLESHOOTING Troubleshooting PRODUCT SPECIFICATIONS Product Specifi cations English _ 5... - Page 6 product introduction FEATURES This model is an elegant-looking proximity reader that can be easily attached to a metal doorframe or the wall. Featured by the epoxy adhesion and aluminium case, R1001V/R1101V is shock-resistant with a high level of weather-proofi ng in any challenging weather conditions. The red and green indicators as well as the Piezo buzzer guarantee a stable and proper operation for you.
- Page 7 AT A GLANCE Front/Rear Displays the system operation status using red and green indicators. Buzzer Piezo buzzer. Connection Cable Used to connect to the power or I/O cable. Fixing Hole Fixing hole for wall-mounting. Tamper Switch A tamper switch to detect falling from the wall. English _ 7...
- Page 8 product introduction CABLE COLOR SCHEME Item Cable Color Signal Line Description DC +12V DC +12V supplied Power Black Earth-grounding for power Blue Buzzer Control BUZZER Control Input Port Input Yellow LED Control LED Control Input Port Green Out Wiegand 0 Wiegand Data 0 Output Port Output White...
-
Page 9: Installation
installation and external connection INSTALLATION - Inserted in the doorframe / attached to the wall Two 6-32 or M3 holes are 3.3” (8.38 cm) away from each other vertically; between the two exists one 1/2” hole through which the reader cables are arranged. The midway hole is located 1.7” (4.31cm) down from the upper hole. (If the product is already installed, you can skip the follow step) Insert the reader cables to the midway hole and fi... -
Page 10: Precautions On Installation
installation and external connection PRECAUTIONS ON INSTALLATION If installing on a metal wall If you install the reader on a metal wall, the read range may be reduced. To avoid this problem, it is recommended to insert the spacer between the metal wall and the reader as shown below. Metal Wall Spacer... -
Page 11: External Connection
EXTERNAL CONNECTION Wiring Diagram SSA-R1001V/SSA-R1101V RS-232(TX) Brown Buzzer Control In Blue Yellow LED Control In Green Wiegand Data 0 Out Black RS-232(GND) CONTROLLER White Wiegand Data 1 Out Tamper Output(COM) Pink Tamper Output(NC) Light yellow Black DC +12V POWER Item Cable Wiring Connect the DC+12V to the red line. -
Page 12: Basic Operations
initialization BASIC OPERATIONS Initial State (when the power is supplied) When you apply power to the reader, it will sound a beep before entering Standby with the red indicator turn on . Using the card Present the card to the reader until you hear a beep and the red indicator turns green. When the reader has transferred the data to the controller, it returns to Standby with the red indicator turned on and waits for reading the next card. -
Page 13: Wiegand Output
output format WIEGAND OUTPUT Timing Diagram 100us DATA-0 DATA-1 *n : 34 LOGIC Data Type • Bit 1 : Even Parity (bit2~bit17) • Bit2~Bit33 : 4 byte ID number • Bit34 : Odd Parity (bit18~bit33) English _ 13... -
Page 14: Rs-232 Output
output format RS-232 OUTPUT Output Waveform +15V Space(=0) Indeterminate Region Mark(=1) 8 Data Bits -15V 2 Stop Bits Start Bit Data packet corresponding to ASCII character ‘A’ Data Type Start (0X02H) Data (10 Char) End (0x03H) START(0X02H) DATA (10 Char) END (0x03H) ... -
Page 15: Troubleshooting
troubleshooting TROUBLESHOOTING If the product does not function properly, please see the below for trouble shooting. PROBLEM SOLUTION My card is not read properly. Check the rated voltage specifi ed in the user manual and the catalog. Ensure that you are using an ISO14443 Type A card. - Cards of 125 kHz format can not be used. -
Page 16: Product Specifi Cations
product specifi cations PRODUCT SPECIFICATIONS Item SSA-R1001V SSA-R1101V Power / Current DC 12V / Max.80mA Reading Time (Card) 30ms Input Port 2ea : External LED Control, External Buzzer Control Output Port 34bit Wiegand LED Indicator 2 Color LED (Red and Green) Beeper Piezo Buzzer Operating Temperature... - Page 17 TEL : +82-70-7147-8740~60 FAX : +82-31-8018-3745 SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 1480 Charles Willard St, Carson, CA 90746, UNITED STATES Samsung House, 1000 Hillswood Drive, Hillswood Business Tol Free : +1-877-213-1222 FAX : +1-310-632-2195 Park Chertsey, Surrey, UNITED KINGDOM KT16 OPS www.samsungcctvusa.com TEL : +44-1932-45-5300 FAX : +44-1932-45-5325 www.samsungsecurity.com...
