Page 1: User Manual
SSA-S1000 Standalone RFID Access Controller user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please visit our website. www.samsungsecurity.com... -
Page 2: Safety Information
If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifi cations or attempted repair.) . When cleaning, do not spray water directly onto parts of the product. Doing so may cause fi re or electric shock. -
Page 3: Important Safety Instructions
Keep out of direct sunlight and heat radiation sources. It may cause fi re. Install it in a place with good ventilation. Avoid aiming the controller directly towards extremely bright objects such as sun. Apparatus shall not be exposed to dripping or splashing and no objects fi lled with liquids, such as vases, shall be placed on the apparatus. -
Page 4: Table Of Contents
contents PRODUCT INTRODUCTION INSTALLATION AND EXTERNAL CONNECTION SYSTEM INITIALIZATION & BASIC OPERATIONS PRODUCT SPECIFICATIONS Feature What’s included At a Glance Cable Color Scheme Cable Selection Installation Bypass Diode Connection I/O Connection Initializing the system by short-circuiting Basic Operations To register /delete Master ID To register/delete ID card Product Specifi... - Page 5 product introduction FEATURE This product is designed for use with one-door access control for security applications. With its compact design, you can install this product on the wall or a doorframe; Its epoxy molding guarantees stable operation in a challenging environment. This product enables you to control the door using the user card and provides a simple method to register or delete cards, and initialize the system, which is, one of the most convenient and safest door controller.
-
Page 6: What's Included
product introduction WHAT’S INCLUDED Check if the following items are included in the product package. Main Module 3.5 x 40mm Screws (x2) 3.5 x 25mm Screws (x2) 6 x 30mm Plastic Anchors (x2) CD Manual Product Introduction Master Card (x1) Bezel Diode (X 2) Quick Guide... -
Page 7: At A Glance
AT A GLANCE Front/Rear Fixing Hole Connection Cable Program Port Buzzer Displays the system operation status using red and green indicators. Fixing hole for wall-mounting. Used to connect to the power or I/O cable. Port used to upgrade the fi rmware. Piezo buzzer. -
Page 8: Cable Color Scheme
product introduction CABLE COLOR SCHEME Item Cable Color Power Black Yellow Input Blue Green Purple Output White Gray Not used Orange Brown CABLE SELECTION Item Power (DC +12V) Door Contact Sensor Exit Button Sensor Input Door Lock Alarm Device Product Introduction Signal Line DC+12V AUX INPUT#1... -
Page 9: Installation
6-32 hole - On a doorframe or the wall Drill a 1/2-inch (12.7 mm) hole onto the center of the doorframe or the wall where SSA-S1000 is installed, which makes room for the cable of the reader module. Drill two 0.3-inch (7.62 mm) holes: one on the point of 0.39 inch (10 mm) horizontally to the right, 1.74 inch (44.4 mm) vertically up from the center hole, and one on the point of 0.33 inch (8.5 mm) horizontally to the left,... - Page 10 installation and external connection I/O CONNECTION Input Connection Door Contact Sensor Exit Button - To connect the power supply unit Connect the DC+12V to the red line. Connect GND to the black line. - To connect the Door Contact Sensor Connect the COM port of the sensor to the blue line.
- Page 11 Output Connection DOOR LOCK OUT (white) Door Lock Alarm Device Cathode Anode 1N4004 ~ 1N4007 or equiv. - To connect the power supply unit Connect the DC+12V to the red line. Connect GND to the black line. - To connect the door lock device Connect the plus(+) line of the lock device to DC+12V.
-
Page 12: Initializing The System By Short-Circuiting
system initialization & basic operations INITIALIZING THE SYSTEM BY SHORT-CIRCUITING Turn off the product and short-circuit three lines: white line of the door lock device, green line of the Exit button, and yellow line of the lock type. When you turn the product back on, all of the LED indicators turn red or green, repeat turning on/off twice before being completely turned off. -
Page 13: To Register /Delete Master Id
LED indicators turn red, starting with the fi rst three LED indicators from the top turning from green to red. If you present a registered user card after the Master Card is deleted, that card will be registered as the Master Card. SSA-S1000 Cable Blue Yellow... -
Page 14: Troubleshooting
The very fi rst card read by the product after turning on the product will be registered as the Master Card. Check if the Exit button is connected to SSA-S1000 properly. (the Exit button should be used with a NO-type button) Check if the Exit button works normally. -
Page 15: Product Specifi Cations
