MODSTER Arrows Husky Operating Manual page 16

Model assembly
Pushrod installation
1. With the servo and elevator centered, connect the
servo to the control surface using a pushrod.
Antenna installation
1. Place the antennae into their positions on top of the
wings as shown, then push them aft to secure.
2. With the servo and rudder centered, connect the
servo to the control surface using a pushrod.
Propeller and spinner installation
1. The propeller and spinner are secured onto the
motor shaft in the order shown.
b
d
c
e
HKM3.0*16mm
a
06
