MODSTER Arrows Husky Operating Manual page 15

Model assembly
Wing installation
3. With the fuselage inverted, connect the aileron
servo wire then secure the wing and wing struts
using the included screws.
Horizontal and vertical stabilizer installation
1. Place the horizontal stabilizer onto the fuselage
cutout.
2. Place the vertical stabilizer onto the horizontal
stabilizer. Secure using the included screw.
05
HKM3.0*32mm
HKM3.0*16mm
3. Attach both tailfins to the fuselage using the
included screws.
KA3.0*16mm
HKM3.0*32mm
