REV A
Wire Type
Wire
Awg.
Stranded
26
24
22
Pull Test Values
26 Awg
24 Awg
22 Awg
(Values based on M22759/11xx)
NOTE 1: Refer to IPC/WHMA-A-620A standard (Ch. 11.1.2) for cable lengths, measurements and tolerance.
NOTE 2: Overall length of cable should be less 3/8" to compensate for the contact attachment,
STEP 1) From the "Contact Crimp Information" Table, use the crimp tool and positioner set listed.
Wiring Assembly Instructions
F01S006 - Contact, Receiver, Signal, Crimp, 4 Amps, 24–26 Awg.
Fig. A. (Contact Sub-Assembly)
Contact Crimp Information Table
Strip Length In
Crimp Tool
Inches
A) 1/4"
452200/M
A) 1/4"
A) 1/4"
1.5lbs
5lbs
8lbs
Hex Die Set/
Indicator
Positioner
452215
N/A
(Example of Equipment)
IN F01S006
Selector
Heat-shrink
No.
Length X Dia.
3
N/A
4
5
Page 1 of 2
Advertisement
Table of Contents
Related Manuals for MAC Panel F01S006
Summary of Contents for MAC Panel F01S006
- Page 1 REV A IN F01S006 Wiring Assembly Instructions F01S006 - Contact, Receiver, Signal, Crimp, 4 Amps, 24–26 Awg. Fig. A. (Contact Sub-Assembly) Contact Crimp Information Table Wire Type Wire Strip Length In Crimp Tool Hex Die Set/ Indicator Selector Heat-shrink Awg.
- Page 2 REV A IN F01S006 Fig. B. (Crimp Tool 452200/M) Detail A. (Positioner and Crimp Tool) STEP 2) Insert the Positioner into the Crimp Tool and rotate until the two Location Pins lock in place by pushing the positioner and rotating as shown in Fig. C. and D. below.
