REV A
Wire
Wire
Strip Length In
Type
Awg.
Stranded
20
18
Pull Test Values
20 Awg
18 Awg
(Values based on M22759/11xx)
NOTE 1: Refer to IPC/WHMA-A-620A standard (Ch. 11.1.2) for cable lengths, measurements and tolerance.
NOTE 2: Overall length of cable should be less 3/8" to compensate for the contact attachment.
STEP 1) From the "Contact Crimp Information" Table, use the crimp tool and hex die set listed.
Fig. B. (Crimp Tool 452200/M)
Wiring Assembly Instructions
M02S006M-02 Contact, ITA, Signal, Crimp 4 Amp 20-26 Awg
Fig. A. (Contact Sub-Assembly)
Contact Crimp Information Table
Crimp Tool
Inches
A) 3/16"
452200/M
A) 3/16"
13lbs
25lbs
Hex Die Set/
Indicator
Positioner
452218
N/A
(Example of Equipment)
Detail A. (Positioner and Crimp Tool)
IN M02S006M-02
.
Selector
Heat-shrink
No.
Length X Dia.
7
N/A
6
Page 1 of 2
Advertisement
Table of Contents
Related Manuals for MAC Panel M02S006M-02
Summary of Contents for MAC Panel M02S006M-02
- Page 1 REV A IN M02S006M-02 Wiring Assembly Instructions M02S006M-02 Contact, ITA, Signal, Crimp 4 Amp 20-26 Awg Fig. A. (Contact Sub-Assembly) Contact Crimp Information Table Wire Wire Strip Length In Crimp Tool Hex Die Set/ Indicator Selector Heat-shrink Type Awg. Inches Positioner Length X Dia.
- Page 2 REV A IN M02S006M-02 STEP 2) Insert the Positioner into the Crimp Tool and rotate until the two Location Pins lock in place by pushing the positioner and rotating as shown in Fig. C. and D. below. Fig. C. (Positioner) Fig.
