REV A
40-220003-01 Contact, ITA, Micro Power, Crimp, 23Amps, 14Awg Max
Wire
Wire
Strip Length In
Type
Awg.
Stranded
18
16
14
Pull Test Values
18 Awg
16 Awg
14 Awg
(Values based on M22759/11xx)
NOTE 1: Refer to IPC/WHMA-A-620A standard (Ch. 11.1.2) for cable lengths, measurements and tolerance.
NOTE 2: Overall length of cable should be less 3/8" to compensate for the contact attachment.
STEP 1) From the "Contact Crimp Information" Table, use the Crimp Tool and Positioner set listed.
Wiring Assembly Instructions
Fig. A. (Contact Sub-Assembly)
Contact Crimp Information Table
Crimp Tool
Inches
A) 1/4"
452200
A) 1/4"
A) 1/4"
32lbs
39lbs
48lbs
Hex Die Set/
Indicator
Positioner
452220
Yellow
Yellow
Yellow
(Example of Equipment)
IN 40-220003-01
.
Selector
Heat-shrink
No.
Length X Dia.
4
N/A
5
5
Page 1 of 3
Advertisement
Table of Contents
Related Manuals for MAC Panel 40-220003-01
Summary of Contents for MAC Panel 40-220003-01
- Page 1 REV A IN 40-220003-01 Wiring Assembly Instructions 40-220003-01 Contact, ITA, Micro Power, Crimp, 23Amps, 14Awg Max Fig. A. (Contact Sub-Assembly) Contact Crimp Information Table Wire Wire Strip Length In Crimp Tool Hex Die Set/ Indicator Selector Heat-shrink Type Awg. Inches Positioner Length X Dia.
- Page 2 REV A IN 40-220003-01 Fig. B. (Crimp Tool 452200) Detail A. (Positioner and Crimp Tool) STEP 2) Insert the Positioner into the Crimp Tool as shown in Fig. C. below. Fig. C. (Positioner inserted into Crimp Tool) STEP 3) Strip wire to dimensions in “Contact Crimp Information” Table using a ruler along with a wire stripper as shown in Fig.
- Page 3 REV A IN 40-220003-01 Page 3 of 3...
