PLEASE READ
BEFORE COMMENCING
OPERATION
This machine is suitable for DRY use
only.
Make sure that the filtration system
fitted to the machine is suitable for the
material being collected.
HZC 390L-2
HZC 390S-2
Owner Instructions
CAUTION Read the Instructions before using the machine.
HZC 390S-2 / HZC 390L-2
1000W (Kit AA16)
www.numatic.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HZC 390S-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Numatic HZC 390S-2

Summary of Contents for Numatic HZC 390S-2

  • Page 1 Make sure that the filtration system fitted to the machine is suitable for the material being collected. HZC 390L-2 HZC 390S-2 Owner Instructions CAUTION Read the Instructions before using the machine. HZC 390S-2 / HZC 390L-2 1000W (Kit AA16) www.numatic.co.uk...

  • Page 2: Handle Assembly

    Kit AA16 601101 2.4 NuFlex Threaded Hose 601144 65mm Soft dusting brush 602161 152mm Rubber Dusting Brush with soft bristles 601141 Double taper hose / tool adaptor 601142 240mm Crevice tool 601917 280mm Stainless steel gulper / scraper tool 602159 38 / 32mm Adaptor Handle Assembly...
  • Page 3 Air Diffuser Hose...
  • Page 4 Machine Function Moving your Machine...

  • Page 5: Replacing The Cartridge Filter

    Replacing the Cartridge Filter Seal contaminated hose using bung supplied. 2/3. Remove the sealed H Class Filter Unit from the drum. Place the Filter Unit and Hose Assembly inside an impervious plastic bag and seal the bag. Dispose of the plastic bag, depending on contamination, in an appropriate manner. Note* Filter unit is sealed do not attempt to open and reuse.
  • Page 6 Low Flow Warning Light Lo - Flo Indicator. Slow Repeated Flash. The vacuum cleaner is fitted with a warning lamp that will illuminate and flash when the air speed in the suction hose falls below <20m/s. This indicates that the filter cartridge requires changing. Cause Solution Suction hose blocked or kinked.
  • Page 7 Changing / Replacing Cable...

  • Page 8: Rating Label

    Protection NOTE: A risk assessment should be conducted to determine which PPE should be worn. Failure to rectify the problem or in the event of a breakdown contact your Numatic dealer or the Numatic Technical helpline +44 (0)1460 269268 Safety Critical Components H05VV-F 10 m x 3 Core x 1.0 mm²...
  • Page 9 • Regularly examine the power cord. If damage is found such as cracking or ageing the power cord must be replaced by a qualifi ed person using the correct Numatic original part. • Change 908082 H Class Filter Unit with the correct Numatic approved replacement part.
  • Page 10 (Lamp will illuminate at preset air velocity levels < 20 m/s). This machine must only be repaired by suitably trained and authorised personnel. Only use genuine Numatic International Ltd spare parts, for repairs. This machine must not be installed as a fi xed extraction system or run unattended.
  • Page 11 Regularly examine the supply cord for damage, such as cracking or ageing. If damage is found, replace the cord before further use. All parts of this vacuum are safety critical only replace with the genuine Numatic spare parts. For user servicing, the machine must be dismantled, cleaned and serviced, as far as is reasonably practicable, without causing risk to maintenance staff and others.

  • Page 12: Replacement Parts

    Data Weight Sound Pressure Cleaning Protection Drum Size (Ready to (LpA) Range Class work) Uncertainty (KpA) HZC 390S-2 13 L 12.2 kg 74.48 dB (A) 26.8 m Class I HZC 390L-2 13 L 13.0 kg 0.5 dB Max. Dimensions Low flow...
  • Page 13 H. Numatic International Limited reserve the right to charge for any unnecessary work carried out as a result of an invalid claim. I. No variation to this warranty may be made or implied by any member of Numatic International Limited or its Dealers unless such variation is in writing and authorised by the Company.
