PLEASE READ
BEFORE COMMENCING
OPERATION
This machine is suitable for DRY
use only.
Make sure that the filtration system
fitted to the machine is suitable for
the material being collected.
HZ 390-L2
HZ 390-S2
Owner Instructions
Warning! Read the Instructions before using the machine.
HZ 390-S2 / HZ 390-L2
1200W (Kit AA18)
www.numatic.co.uk

Advertisement

Table of Contents
loading

Related Manuals for Numatic HZ 390-S2

Summary of Contents for Numatic HZ 390-S2

  • Page 1 Make sure that the filtration system fitted to the machine is suitable for the material being collected. HZ 390-L2 HZ 390-S2 Owner Instructions Warning! Read the Instructions before using the machine. HZ 390-S2 / HZ 390-L2 1200W (Kit AA18) www.numatic.co.uk...

  • Page 2: Handle Assembly

    Kit AA18 601101 2.4 NuFlex Threaded Hose 601144 65mm Soft dusting brush 218016 NVM-2BH HEPAFLO filter bags 629445 Roll of 10x 120 litre waste bags, white 601142 240mm Crevice tool 601141 Double taper hose / tool adaptor 602159 38 / 32mm Adaptor 601917 280mm Stainless steel gulper / scraper tool 604165 TriTex filter for 305mm machines 602161 152mm Rubber brush with soft bristles (38mm)
  • Page 3 Air Diffuser Hose...
  • Page 4 Machine Function Moving your Machine...
  • Page 5 Changing the bag, cleaning the filter Remove the cloth filter (A) from the drum. Remove the HEPAFLO dust bag and seal the dust bag hole. Place the dust bag inside an impervious plastic bag and seal the bag. Dispose of the plastic bag, depending on contamination, in an appropriate manner.
  • Page 6 Cleaning your TriTex Filter...

  • Page 7: Replacing The Cartridge Filter

    Replacing the Cartridge Filter 901649 H13 Filter Cartridge...
  • Page 8 Low Flow Warning Light Lo - Flo Indicator. This appliance is fitted with a low flow indicator to show that air flow has reduced. In the event of the indicator light flashing, check the following:- Cause Solution Dust caps still fitted Remove the caps.
  • Page 9 Changing / Replacing Cable...

  • Page 10: About The Machine

    About the Machine Rating Label Company Name & Address Machine Description Voltage / Frequency Power rating IPX Rating Weight (ready to use) Type Hazardous CE Mark WEEE Logo Machine yr/wk Serial number Safety Critical Component: Mains Lead H05VV-F 10m x 3 x 1.0mm² WEEE (Waste, Electrical and Electronic Equipment) Vacuum Cleaner Accessories and packaging should be sorted for environmentally-friendly recycling.
  • Page 11 Replace any worn or damaged parts immediately. • Regularly examine the power cord. If damage is found such as cracking or ageing the power cord must be replaced by a qualified person using the correct Numatic original part. • Change dust bag frequently.

  • Page 12: Important User Information

    Only use the dust collection bag (NVM-2BH) once. This machine must only be repaired by suitably trained and authorised personnel. Only use genuine Numatic International Ltd spare parts, for repairs. This machine must not be installed as a fixed extraction system or run unattended.

  • Page 13: Maintenance

    Regularly examine the supply cord for damage, such as cracking or ageing. If damage is found, replace the cord before further use. All parts of this vacuum are safety critical only replace with the genuine Numatic spare parts. For user servicing, the machine must be dismantled, cleaned and serviced, as far as is reasonably practicable, without causing risk to maintenance staff and others.

  • Page 14: Replacement Parts

    10 x Hepaflo Filter bag NVM 2BH 908229 Roll of 10x 120 litre waste bags, grey 901649 H13 Filter Cartridge Data HZ 390-S2 9.3 L 25 m 11.2 kg 71.79 dB (A) Class I 400 x 450 x 600 mm HZ 390-L2 12.6 kg...
  • Page 16 Distributed by: Numatic International Limited. Chard, Somerset TA20 2GB ENGLAND Tel.: 01460 68600 www.numatic.co.uk Specification subject to change without prior notice www.numatic.co.uk © Numatic International Limited 908328 08/18 (A01)

This manual is also suitable for:

Hz 390-l2
