PLEASE READ
BEFORE COMMENCING
OPERATION
This machine is suitable for DRY
use only.
Make sure that the filtration system
fitted to the machine is suitable for
the material being collected.
HZC 390L-2
HZC 390S-2
Owner Instructions
Warning! Read the Instructions before using the machine.
HZC 390S-2 / HZC 390L-2
1000W (Kit AA16)
www.numatic.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HZC 390S-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Numatic HZC 390S-2

Summary of Contents for Numatic HZC 390S-2

  • Page 1 Make sure that the filtration system fitted to the machine is suitable for the material being collected. HZC 390L-2 HZC 390S-2 Owner Instructions Warning! Read the Instructions before using the machine. HZC 390S-2 / HZC 390L-2 1000W (Kit AA16) www.numatic.co.uk...

  • Page 2: Handle Assembly

    Kit AA16 601101 2.4 NuFlex Threaded Hose 601144 65mm Soft dusting brush 602161 152mm Rubber Dusting Brush with soft bristles 601141 Double taper hose / tool adaptor 601142 240mm Crevice tool 601917 280mm Stainless steel gulper / scraper tool 602159 38 / 32mm Adaptor Handle Assembly...
  • Page 3 Air Diffuser Hose...
  • Page 4 Machine Function Moving your Machine...

  • Page 5: Replacing The Cartridge Filter

    Replacing the Cartridge Filter Seal contaminated hose using bung supplied. 2/3. Remove the sealed H Class Filter Unit from the drum. Place the Filter Unit and Hose Assembly inside an impervious plastic bag and seal the bag. Dispose of the plastic bag, depending on contamination, in an appropriate manner. Note* Filter unit is sealed do not attempt to open and reuse.
  • Page 6 Low Flow Warning Light Lo - Flo Indicator. Slow Repeated Flash. The vacuum cleaner is fitted with a warning lamp that will illuminate and flash when the air speed in the suction hose falls below <20m/s. This indicates that the filter cartridge requires changing. Cause Solution Suction hose blocked or kinked.
  • Page 7 Changing / Replacing Cable...

  • Page 8: About The Machine

    About the Machine Rating Label Company Name & Address Machine Description Voltage / Frequency Power rating IPX Rating Weight (ready to use) Type Hazardous CE Mark WEEE Logo Machine yr/wk Serial number Safety Critical Component: Mains Lead H05VV-F 3 Core x 1.0mm² x 10m (110V) H05VV-F 3 Core x 1.5mm²...
  • Page 9 • Regularly examine the power cord. If damage is found such as cracking or ageing the power cord must be replaced by a qualified person using the correct Numatic original part. • Change 908082 H Class Filter Unit with the correct Numatic approved replacement part.

  • Page 10: Important User Information

    (Lamp will illuminate at preset air velocity levels < 20 m/s). This machine must only be repaired by suitably trained and authorised personnel. Only use genuine Numatic International Ltd spare parts, for repairs. This machine must not be installed as a fixed extraction system or run unattended.

  • Page 11: Maintenance

    Regularly examine the supply cord for damage, such as cracking or ageing. If damage is found, replace the cord before further use. All parts of this vacuum are safety critical only replace with the genuine Numatic spare parts. For user servicing, the machine must be dismantled, cleaned and serviced, as far as is reasonably practicable, without causing risk to maintenance staff and others.

  • Page 12: Replacement Parts

    H Class Sealed Filter Kit Data Weight Drum Cleaning Protection (Ready to Sound Pressure Size Range Class work) HZC 390S-2 13 Ltr 12.2 kg 68.76 dB (A) 26.8 m Class I HZC 390L-2 13 Ltr 13.0 kg Uncertainty 0.5 dB Max. Dimensions...
  • Page 13 H. Numatic International Limited reserve the right to charge for any unnecessary work carried out as a result of an invalid claim. I. No variation to this warranty may be made or implied by any member of Numatic International Limited or its Dealers unless such variation is in writing and authorised by the Company.

  • Page 14: Declaration Of Conformity

    Declaration of Conformity...
  • Page 15 Notes ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 16 Distributed by: Numatic International Limited. Chard, Somerset TA20 2GB ENGLAND Tel.: 01460 68600 www.numatic.co.uk Specification subject to change without prior notice www.numatic.co.uk © Numatic International Limited 908545 01/19 (A04)
